Page 1
NLS-FR40 Fixed Mount Barcode Scanner User Guide...
Page 2
All pictures in this manual are for reference only and actual product may differ. Regarding to the product modification and update, Fujian Newland Auto-ID Tech. Co., Ltd. reserves the right to make changes to any software or hardware to improve reliability, function, or design at any time without notice.
Table of Contents Revision History......................................- 3 - Preface..........................................1 Introduction......................................1 Chapter Description.................................... 1 Explanation of Icons....................................2 Chapter 1 Getting Started....................................3 Introduction......................................3 Features of the FR40..................................3 Unpacking......................................3 FR40 Scanner...................................... 4 The Pinout of the Data Port (default)............................... 5 Connecting the FR40 to a Host.................................5 Using USB Cable..................................6 Using RS-232 Cable...................................
Page 8
Transmit Start/Stop Character............................67 Set Length Range for Code 39............................68 Check Digit Verification..............................69 Enable/Disable Code 39 Full ASCII..........................70 Codabar...................................... 71 Restore Factory Defaults..............................71 Enable/Disable Codabar..............................71 Set Length Range for Codabar............................72 Check Digit Verification..............................73 Start/Stop Character................................. 74 Code 93......................................
Page 9
Restore Factory Defaults..............................85 Enable/Disable Industrial 25............................85 Set Length Range for Industrial 25..........................86 Check Digit Verification..............................87 Standard 25 (IATA 2 of 5).................................88 Restore Factory Defaults..............................88 Enable/Disable Standard 25............................88 Set Length Range for Standard 25..........................89 Check Digit Verification..............................90 Plessey......................................91 Restore Factory Defaults..............................
Page 10
Enable/Disable Data Matrix............................105 Set Length Range for Data Matrix..........................106 Data Matrix Twin Code..............................107 Rectangular Barcode..............................108 Mirror Image..................................108 Chapter 8 Prefix & Suffix.................................... 109 Introduction...................................... 109 Global Settings....................................110 Enable/Disable All Prefix/Suffix............................. 110 Prefix Sequences..................................110 Custom Prefix....................................111 Enable/Disable Custom Prefix...............................111 Set Custom Prefix..................................111 AIM ID Prefix....................................
Preface Introduction This manual provides detailed instructions for setting up and using the NLS-FR40XX-3X fixed mount barcode scanner (hereinafter referred to as “FR40 scanner” or “the scanner”). Chapter Description Chapter 1, Getting Started : Gives a general description of FR40 scanner. ...
Explanation of Icons This icon indicates something relevant to this manual. This icon indicates this information requires extra attention from the reader. This icon indicates handy tips that can help you use or configure the scanner with ease. This icon indicates practical examples that can help you to acquaint yourself with operations.
The FR40 scanner reads a 1D or 2D barcode by capturing its image. Adopting the advanced technology independently developed by Newland Auto-ID Tech, it provides users with Regular mode and Screen mode, tailored to different scanning needs. An illustrated introduction to the FR40 scanner is included in this chapter. If you have an FR40 scanner at hand, make good use of it to develop a better understanding of this manual.
FR40 Scanner Regular/Screen Mode Switch (LED) Regular/Screen Mode Switch: Trigger (Left) Press it to toggle between the Screen mode (red LED lights up) and Regular Scan Window mode (green LED lights up). LED: LED flashes once: Barcode is decoded. Trigger (Right) Data Port...
The Pinout of the Data Port (default) Signal Type Function No connection No connection Power+ (+5V) RS-232 output RS-232 input No connection No connection Ground USB signal Connecting the FR40 to a Host The FR40 scanner must be connected to a Host in actual application, such as PC, POS or any intelligent terminal with USB or RS-232 port, via a communication cable, either USB or RS-232 cable.
Using USB Cable Connect the FR40 scanner to a Host through a USB cable with RJ45 and USB connectors: Plug the RJ45 connector into the data port on the scanner. Plug the USB connector into the USB port on the Host.
Using RS-232 Cable Connect the FR40 scanner to a Host through a RS-232 cable with RJ45, RS-232 and power connectors: Plug the RJ45 connector into the data port on the scanner. Plug the RS-232 connector into the RS-232 port on the Host. Connect the supplied power adaptor to the power connector of the RS-232 cable.
Power On, Power Off, Reboot Power on the scanner Connect the FR40 scanner to a Host. Then the scanner will be turned on. Power off the scanner Remove the communication cable from the FR40 scanner; or remove the USB cable from the Host; or disconnect the power adaptor from mains.
Scanning Instructions When the FR40 scanner is in the Sense scan mode, you can follow the steps below to scan a barcode: Connect the scanner to a Host with the cable. Then the scanner will be powered on. Present a barcode to the center of the scan window. Then the scanner will project a red beam and start to decode the barcode.
【Enter Setup】 Chapter 2 System Settings Introduction There are two ways to configure the FR40 scanner: barcode programming and command programming. Barcode Programming The FR40 scanner can be configured through scanning a number of programming barcodes. In the following sections, we will explain the available options and features and provide the barcodes to program them.
【Enter Setup】 Programming Barcode/Command/Function The figure above is an example that shows you the programming barcode and command for the Exit Setup function: 1. The Exit Setup barcode 2. The Exit Setup command 3. The function/feature that can be enabled by using the programming barcode or command listed above. 4.
【Enter Setup】 Programming barcode data can be transmitted to the Host. Scan the appropriate barcode below to enable or disable the transmission of programming barcode data (programming commands) to the Host. **【Do Not Transmit Programming Barcode Data】 【Transmit Programming Barcode Data】 Beep Good Read Beep Scanning the Good Read Beep Off barcode disables the scanner’s ability to beep upon a successful decode of...
【Enter Setup】 Beep on Unknown Character Due to the differences in keyboard layouts, some characters contained in barcode data may be unavailable on the selected keyboard. As a result, the scanner fails to transmit the unknown characters. Scan the appropriate barcode below to enable or disable the emission of beep when an unknown character is detected. **【Do Not Beep on Unknown Character】...
【Enter Setup】 Transmit NGR Message Scan the appropriate barcode below to select whether or not to transmit a user-defined NGR (Not Good Read) message when the scanner fails to decode a barcode. 【Transmit NGR Message】 **【Do Not Transmit NGR Message】 Edit NGR Message To edit an NGR message, scan the Edit NGR Message barcode and the numeric barcodes corresponding to the ASCII values (hex) of desired characters and then scan the Save barcode.
【Enter Setup】 Default Settings Factory Defaults Scanning the following barcode can restore the scanner to the factory defaults. You may need to reset all parameters to the factory defaults when: scanner is not properly configured so that it fails to decode barcodes. ...
【Enter Setup】 Chapter 3 Scanning Preferences The scanner can capture barcodes printed on paper labels or displayed on the screen of a mobile phone. Select a mode that fits your application.. Regular Mode: Read barcodes printed on paper or objects. ...
【Enter Setup】 Chapter 4 Scan Mode Sense Mode If the Sense mode is enabled, presenting a barcode to the scanner activates a decode session. The session continues until the barcode decodes or the decode session timeout expires or the barcode is moved away from the scanner. Holding down the left or right trigger on the scanner can also activate a decode session.
【Enter Setup】 Batch Mode If the Batch Mode is enabled, presenting barcodes one after another to the scanner or holding down the left or right trigger activates a round of multiple decode sessions. This round of multiple scans continues until you release the trigger or stop presenting barcode to the scanner.
【Enter Setup】 Continuous Mode If the Continuous mode is enabled, the scanner automatically activates one decode session after another. Mode】 【Continuous Decode Session Timeout This parameter sets the maximum time decode session continues during a scan attempt. If the timeout expires or the barcode decodes, the decode session stops.
【Enter Setup】 Timeout between Decodes This parameter sets the timeout between decode sessions. When a decode session ends, next session will not happen until the timeout between decodes expires. It is programmable in 1ms increments from 0ms to 65,535ms. The default setting is 1,000ms.
【Enter Setup】 Chapter 5 RS-232 Interface Introduction When the scanner is connected to the RS-232 port of a Host, you need to scan the barcode below to enable RS-232 communication and set communication parameters (including baud rate, parity check, data bit and stop bit) to match the Host.
【Enter Setup】 Baud Rate Baud rate is the number of bits of data transmitted per second. Set the baud rate to match the Host requirements. **【9600】 【19200】 【1200】 【38400】 【2400】 【57600】 【4800】 【115200】 【14400】 **【Exit Setup】...
【Enter Setup】 Parity Check Set the parity type to match the Host requirements. Odd Parity: If the data contains an odd number of 1 bits, the parity bit value is set to 0. Even Parity: If the data contains an even number of 1 bits, the parity bit value is set to 0. ...
【Enter Setup】 Data Bit Set the number of data bits to match the Host requirements. **【8 Data Bits】 【7 Data Bits】 Data Bit & Parity Check 【7 Data Bits/Even Parity】 【7 Data Bits/Odd Parity】 **【8 Data Bits/ No Parity】 【8 Data Bits/Even Parity】 【8 Data Bits/Odd Parity】...
【Enter Setup】 Stop Bit The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and prepares the receiving device for the next character in the serial data stream. Set the number of stop bits to match the Host requirements.
【Enter Setup】 Chapter 6 USB Interface Introduction There are two options for USB connection. USB HID-KBW: The scanner’s transmission is simulated as USB keyboard input with no need for command configuration or a driver. The barcode data could be entered by the virtual keyboard directly and it is also convenient for the Host to receive data.
【Enter Setup】 USB Country Keyboard Types Keyboard layouts may vary from country to country. The default setting is US keyboard type. **【U.S.】 【Japan】 【Denmark】 【Finland】 【France】 【Turkey_F】 【Italy】 【Norway】 **【Exit Setup】...
【Enter Setup】 Beep on Unknown Character Due to the differences in keyboard layouts, some characters contained in barcode data may be unavailable on the selected keyboard. As a result, the scanner fails to transmit the unknown characters. Scan the appropriate barcode below to enable or disable the emission of beep when an unknown character is detected. **【Do Not Beep on Unknown Character】...
【Enter Setup】 Convert Case Scan the appropriate barcode below to convert all bar code data to your desired case. **【No Case Conversion】 【Invert Upper and Lower Case Characters】 【Convert All to Upper Case】 【Convert All to Lower Case】 When the Invert Upper and Lower Case Characters feature is enabled, barcode data “AbC” is transmitted as “aBc”.
【Enter Setup】 USB COM Port Emulation If your scanner is connected to the USB port on a Host, the USB COM Port Emulation feature allows the Host to receive data in the way as a serial port does. However, you need to set communication parameters on the scanner to match the Host requirements.
【Enter Setup】 Chapter 7 Symbologies Introduction Every symbology (barcode type) has its own unique attributes. This chapter provides programming barcodes for configuring the scanner so that it can identify various barcode symbologies. The more symbologies you enable, the more slowly your scanner decodes. It is recommended to disable those that are rarely used to improve the performance of the scanner.
【Enter Setup】 Video Reverse Regular barcode: Dark image on a bright background. Inverse barcode: Bright image on a dark background. The examples of regular barcode and inverse barcode are shown below. Regular Barcode Inverse Barcode Video Reverse is used to allow the scanner to read barcodes that are inverted. Video Reverse ON: Read both regular barcodes and inverse barcodes.
【Enter Setup】 1D Symbologies Code 128 Restore Factory Defaults **【Restore the Factory Defaults of Code 128】 Enable/Disable Code 128 【Disable Code 128】 **【Enable Code 128】 If the scanner fails to identify Code 128 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 128 barcode.
【Enter Setup】 Set Length Range for Code 128 The scanner can be configured to only decode Code 128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...
【Enter Setup】 AIM-128 Restore Factory Defaults 【Restore the Factory Defaults of AIM-128】 Enable/Disable AIM-128 **【Enable AIM-128】 【Disable AIM-128】 If the scanner fails to identify AIM-128 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable AIM-128 barcode. **【Exit Setup】...
【Enter Setup】 Set Length Range for AIM-128 The scanner can be configured to only decode AIM-128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...
【Enter Setup】 GS1-128(UCC/EAN-128) Restore Factory Defaults **【Restore the Factory Defaults of UCC/EAN-128】 Enable/Disable UCC/EAN-128 **【Enable UCC/EAN-128】 【Disable UCC/EAN-128】 If the scanner fails to identify UCC/EAN-128 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable UCC/EAN-128 barcode. **【Exit Setup】...
【Enter Setup】 EAN-8 Restore Factory Defaults **【Restore the Factory Defaults of EAN-8】 Enable/Disable EAN-8 **【Enable EAN-8】 【Disable EAN-8】 Transmit Check Digit EAN-8 is 8 digits in length with the last one as its check digit used to verify the integrity of the data. **【Transmit EAN-8 Check Digit】...
【Enter Setup】 2-Digit Add-On Code An EAN-8 barcode can be augmented with a two-digit add-on code to form a new one. In the example below, the part surrounded by blue dotted line is an EAN-8 barcode while the part circled by red dotted line is a two-digit add-on code. **【Disable 2-Digit Add-On Code】...
【Enter Setup】 5-Digit Add-On Code An EAN-8 barcode can be augmented with a five-digit add-on code to form a new one. In the example below, the part surrounded by blue dotted line is an EAN-8 barcode while the part circled by red dotted line is a five-digit add-on code. **【Disable 5-Digit Add-On Code】...
【Enter Setup】 Add-On Code Required 【EAN-8 Add-On Code Required】 **【EAN-8 Add-On Code Not Required】 EAN-8 Extension Disable EAN-8 Zero Extend: Transmit EAN-8 barcodes as is. Enable EAN-8 Zero Extend: Add five leading zeros to decoded EAN-8 barcodes to extend to 13 digits. **【Disable EAN-8 Zero Extend】...
【Enter Setup】 2-Digit Add-On Code An EAN-13 barcode can be augmented with a two-digit add-on code to form a new one. In the example below, the part surrounded by blue dotted line is an EAN-13 barcode while the part circled by red dotted line is a two-digit add-on code. **【Disable 2-Digit Add-On Code】...
【Enter Setup】 5-Digit Add-On Code An EAN-13 barcode can be augmented with a five-digit add-on code to form a new one. In the example below, the part surrounded by blue dotted line is an EAN-13 barcode while the part circled by red dotted line is a five-digit add-on code. **【Disable 5-Digit Add-On Code】...
【Enter Setup】 UPC-E Restore Factory Defaults **【Restore the Factory Defaults of UPC-E】 Enable/Disable UPC-E **【Enable UPC-E】 【Disable UPC-E】 If the scanner fails to identify UPC-E barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable UPC-E barcode. Transmit Check Digit UPC-E is 8 digits in length with the last one as its check digit used to verify the integrity of the data.
【Enter Setup】 2-Digit Add-On Code A UPC-E barcode can be augmented with a two-digit add-on code to form a new one. In the example below, the part surrounded by blue dotted line is a UPC-E barcode while the part circled by red dotted line is a two-digit add-on code. **【Disable 2-Digit Add-On Code】...
【Enter Setup】 5-Digit Add-On Code A UPC-E barcode can be augmented with a five-digit add-on code to form a new one. In the example below, the part surrounded by blue dotted line is a UPC-E barcode while the part circled by red dotted line is a five-digit add-on code. **【Disable 5-Digit Add-On Code】...
【Enter Setup】 Add-On Code Required 【UPC-E Add-On Code Required】 **【UPC-E Add-On Code Not Required】 Transmit System Character “0” The first character of UPC-E barcode is the system character “0”. **【Do Not Transmit System Character “0”】 【Transmit System Character “0”】 UPC-E Extension ...
【Enter Setup】 UPC-A Restore Factory Defaults **【Restore the Factory Defaults of UPC-A】 Enable/Disable UPC-A **【Enable UPC-A】 【Disable UPC-A】 If the scanner fails to identify UPC-A barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable UPC-A barcode. Transmit Check Digit UPC-A is 12 digits in length with the last one as its check digit used to verify the integrity of the data.
【Enter Setup】 2-Digit Add-On Code A UPC-A barcode can be augmented with a two-digit add-on code to form a new one. In the example below, the part surrounded by blue dotted line is a UPC-A barcode while the part circled by red dotted line is a two-digit add-on code. **【Disable 2-Digit Add-On Code】...
【Enter Setup】 5-Digit Add-On Code A UPC-A barcode can be augmented with a five-digit add-on code to form a new one. In the example below, the part surrounded by blue dotted line is a UPC-A barcode while the part circled by red dotted line is a five-digit add-on code. **【Disable 5-Digit Add-On Code】...
【Enter Setup】 Add-On Code Required 【UPC-A Add-On Code Required】 **【UPC-A Add-On Code Not Required】 Transmit Preamble Character “0” The preamble character “0” is part of the UPC-A barcode. **【Do Not Transmit Preamble Character “0”】 【Transmit Preamble Character “0”】 The preamble character “0” usually does not appear in printed UPC-A barcodes. **【Exit Setup】...
【Enter Setup】 Interleaved 2 of 5 Restore Factory Defaults **【Restore the Factory Defaults of Interleaved 2 of 5】 Enable/Disable Interleaved 2 of 5 **【Enable Interleaved 2 of 5】 【Disable Interleaved 2 of 5】 If the scanner fails to identify Interleaved 2 of 5 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Interleaved 2 of 5 barcode.
【Enter Setup】 Set Length Range for Interleaved 2 of 5 The scanner can be configured to only decode Interleaved 2 of 5 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 6)】...
【Enter Setup】 Check Digit Verification A check digit is optional for Interleaved 2 o 5 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Interleaved 2 of 5 barcodes as is. ...
【Enter Setup】 ITF-14 ITF-14 is a special kind of Interleaved 2 of 5 with a length of 14 characters and the last character as the check character. By default, ITF-14 is disabled. ITF-14 priority principle: For the Interleaved 2 of 5 barcodes with a length of 14 characters and the last character as the check character, the ITF-14 configurations shall take precedence over the Interleaved 2 of 5 settings.
【Enter Setup】 ITF-6 ITF-6 is a special kind of Interleaved 2 of 5 with a length of 6 characters and the last character as the check character. By default, ITF-6 is disabled. ITF-6 priority principle: For the Interleaved 2 of 5 barcodes with a length of 6 characters and the last character as the check character, the ITF-6 configurations shall take precedence over the Interleaved 2 of 5 settings.
【Enter Setup】 Matrix 2 of 5 Restore Factory Defaults **【Restore the Factory Defaults of Matrix 2 of 5】 Enable/Disable Matrix 2 of 5 【Enable Matrix 2 of 5】 **【Disable Matrix 2 of 5】 If the scanner fails to identify Matrix 2 of 5 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Matrix 2 of 5 barcode.
【Enter Setup】 Set Length Range for Matrix 2 of 5 The scanner can be configured to only decode Matrix 2 of 5 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 6)】...
【Enter Setup】 Check Digit Verification A check digit is optional for Matrix 2 of 5 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Matrix 2 of 5 barcodes as is. ...
【Enter Setup】 Code 39 Restore Factory Defaults **【Restore the Factory Defaults of Code 39】 Enable/Disable Code 39 **【Enable Code 39】 【Disable Code 39】 If the scanner fails to identify Code 39 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 39 barcode.
【Enter Setup】 Set Length Range for Code 39 The scanner can be configured to only decode Code 39 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 4)】...
【Enter Setup】 Check Digit Verification A check digit is optional for Code 39 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Code 39 barcodes as is. ...
【Enter Setup】 Enable/Disable Code 39 Full ASCII You can enable or disable your scanner’s ability to identify all ASCII characters by scanning the appropriate barcode below. 【Disable Code 39 Full ASCII】 **【Enable Code 39 Full ASCII】 **【Exit Setup】...
【Enter Setup】 Codabar Restore Factory Defaults **【Restore the Factory Defaults of Codabar】 Enable/Disable Codabar **【Enable Codabar】 【Disable Codabar】 If the scanner fails to identify Codabar barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Codabar barcode. **【Exit Setup】...
【Enter Setup】 Set Length Range for Codabar The scanner can be configured to only decode Codabar barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...
【Enter Setup】 Check Digit Verification A check digit is optional for Codabar and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Codabar barcodes as is. ...
【Enter Setup】 Start/Stop Character You can set the start/stop characters and choose whether or not to transmit the start/stop characters by scanning the appropriate barcode below. 【Transmit Start/Stop Character】 **【Do Not Transmit Start/Stop Character】 **【ABCD/ABCD as the Start/Stop Character】 **【Start/Stop Character in Uppercase】 【ABCD/TN*E as the Start/Stop Character】...
【Enter Setup】 Code 93 Restore Factory Defaults **【Restore the Factory Defaults of Code 93】 Enable/Disable Code 93 【Disable Code 93】 **【Enable Code 93】 If the scanner fails to identify Code 93 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 93 barcode.
【Enter Setup】 Set Length Range for Code 93 The scanner can be configured to only decode Code 93 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 3)】...
【Enter Setup】 Check Digit Verification Check digits are optional for Code 93 and can be added as the last two digits, which are calculated values used to verify the integrity of the data. Disable: The scanner transmits Code 93 barcodes as is. ...
【Enter Setup】 GS1 Databar(RSS) Restore Factory Defaults **【Restore the Factory Defaults of GS1 Databar】 Enable/Disable GS1 Databar **【Enable GS1 Databar】 【Disable GS1 Databar】 If the scanner fails to identify GS1 Databar barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable GS1 Databar barcode.
【Enter Setup】 Code 11 Restore Factory Defaults **【Restore the Factory Defaults of Code 11】 Enable/Disable Code 11 **【Enable Code 11】 【Disable Code 11】 If the scanner fails to identify Code 11 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 11 barcode.
【Enter Setup】 Set Length Range for Code 11 The scanner can be configured to only decode Code 11 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 2)】...
【Enter Setup】 Check Digit Verification Check digits are optional for Code 11 and can be added as the last one or two digits, which are calculated values used to verify the integrity of the data. If the Disable option is enabled, the scanner transmits Code 11 barcodes as is. 【One Check Digit, MOD11 (Len<=10)】...
【Enter Setup】 ISSN Restore Factory Defaults 【Restore the Factory Defaults of ISSN】 Enable/Disable ISSN 【Enable ISSN】 **【Disable ISSN】 If the scanner fails to identify ISSN barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable ISSN barcode. **【Exit Setup】...
【Enter Setup】 ISBN Restore Factory Defaults **【Restore the Factory Defaults of ISBN】 Enable/Disable ISBN 【Enable ISBN】 **【Disable ISBN】 If the scanner fails to identify ISBN barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable ISBN barcode. Set ISBN Format **【ISBN-13】...
【Enter Setup】 Industrial 25 Restore Factory Defaults **【Restore the Factory Defaults of Industrial 25】 Enable/Disable Industrial 25 **【Enable Industrial 25】 【Disable Industrial 25】 If the scanner fails to identify Industrial 25 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Industrial 25 barcode.
【Enter Setup】 Set Length Range for Industrial 25 The scanner can be configured to only decode Industrial 25 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 6)】...
【Enter Setup】 Check Digit Verification A check digit is optional for Industrial 25 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Industrial 25 barcodes as is. ...
【Enter Setup】 Standard 25 (IATA 2 of 5) Restore Factory Defaults **【Restore the Factory Defaults of Standard 25】 Enable/Disable Standard 25 **【Enable Standard 25】 【Disable Standard 25】 If the scanner fails to identify Standard 25 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Standard 25 barcode.
【Enter Setup】 Set Length Range for Standard 25 The scanner can be configured to only decode Standard 25 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 6)】...
【Enter Setup】 Check Digit Verification A check digit is optional for Standard 25 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Standard 25 barcodes as is. ...
【Enter Setup】 Plessey Restore Factory Defaults **【Restore the Factory Defaults of Plessey】 Enable/Disable Plessey 【Enable Plessey】 **【Disable Plessey】 If the scanner fails to identify Plessey barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Plessey barcode. **【Exit Setup】...
【Enter Setup】 Set Length Range for Plessey The scanner can be configured to only decode Plessey barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...
【Enter Setup】 Check Digit Verification Check digits are optional for Plessey and can be added as the last two digits, which are calculated values used to verify the integrity of the data. Disable: The scanner transmits Plessey barcodes as is. ...
【Enter Setup】 MSI-Plessey Restore Factory Defaults **【Restore the Factory Defaults of MSI-Plessey】 Enable/Disable MSI-Plessey 【Enable MSI-Plessey】 **【Disable MSI-Plessey】 If the scanner fails to identify MSI-Plessey barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable MSI-Plessey barcode. **【Exit Setup】...
【Enter Setup】 Set Length Range for MSI-Plessey The scanner can be configured to only decode MSI-Plessey barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 2)】...
【Enter Setup】 Check Digit Verification Check digits are optional for MSI-Plessey and can be added as the last one or two digits, which are calculated values used to verify the integrity of the data. If the Disable option is enabled, the scanner transmits MSI-Plessey barcodes as is. **【Disable】...
【Enter Setup】 2D Symbologies PDF417 Restore Factory Defaults **【Restore the Factory Defaults of PDF417】 Enable/Disable PDF417 **【Enable PDF417】 【Disable PDF417】 f the scanner fails to identify PDF417 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable PDF417 barcode. **【Exit Setup】...
【Enter Setup】 Set Length Range for PDF417 The scanner can be configured to only decode PDF417 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...
【Enter Setup】 PDF417 Twin Code PDF417 twin code is 2 PDF417 barcodes paralleled vertically or horizontally. Two of them must have the same direction and similar specifications and be placed closely together. There are 3 options for reading PDF417 twin codes: ...
【Enter Setup】 Transmission Order of Twin Code Order 1: Transmit the one containing more information first. Order 2: Transmit the one containing less information first. **【Order 1】 【Order 2】 **【Exit Setup】...
【Enter Setup】 QR Code Restore Factory Defaults **【Restore the Factory Defaults of QR Code】 Enable/Disable QR Code **【Enable QR Code】 【Disable QR Code】 If the scanner fails to identify QR Code barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable QR Code barcode.
【Enter Setup】 Set Length Range for QR Code The scanner can be configured to only decode QR Code barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...
【Enter Setup】 QR Twin Code QR twin code is 2 QR barcodes paralleled vertically or horizontally. Two of them must have the same direction and similar specifications and be placed closely together. There are 3 options for reading QR twin codes: ...
【Enter Setup】 Data Matrix Restore Factory Defaults **【Restore the Factory Defaults of Data Matrix】 Enable/Disable Data Matrix **【Enable Data Matrix】 【Disable Data Matrix】 If the scanner fails to identify Data Matrix barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Data Matrix barcode.
【Enter Setup】 Set Length Range for Data Matrix The scanner can be configured to only decode Data Matrix barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...
【Enter Setup】 Data Matrix Twin Code Data Matrix twin code is 2 Data Matrix barcodes paralleled vertically or horizontally. Two of them must have the same direction and similar specifications and be placed closely together. There are 3 options for reading Data Matrix twin codes: ...
【Enter Setup】 Rectangular Barcode Data Matrix has two formats: Square barcodes having the same amount of modules in length and width: 10*10, 12*12..144*144. Rectangular barcodes having different amounts of models in length and width: 6*16, 6*14... 14*22. **【Enable Rectangular Barcode】 【Disable Rectangular Barcode】...
【Enter Setup】 Chapter 8 Prefix & Suffix Introduction In many applications, barcode data needs to be edited and distinguished from one another. Usually AIM ID and Code ID can be used as identifiers, but in some special cases customized prefix and terminating character suffix like Carriage Return or Line Feed can also be the alternatives.
【Enter Setup】 Global Settings Enable/Disable All Prefix/Suffix Disable All Prefix/Suffix: Transmit scanned data with no prefix/suffix. Enable All Prefix/Suffix: Allow to append Code ID prefix, AIM ID prefix, custom prefix/suffix and terminating character to the scanned data before the transmission. **【Disable All Prefix/Suffix】...
【Enter Setup】 Custom Prefix Enable/Disable Custom Prefix If custom prefix is enabled, you are allowed to append before the scanned data a user-defined prefix that cannot exceed 10 characters. For example, if the custom prefix is “AB” and the scanned data is “123”, the Host will receive “AB123”. **【Disable Custom Prefix】...
【Enter Setup】 AIM ID Prefix AIM (Automatic Identification Manufacturers) ID defines symbology identifier (For the details, see the AIM ID Table section in Appendix). If AIM ID prefix is enabled, the scanner will add the symbology identifier before the scanned data after decoding.
【Enter Setup】 Restore All Default Code IDs For the information of default Code IDs, see the Code ID Table section in Appendix. 【Restore All Default Code IDs】 Modify Code ID See the examples below to learn how to modify a Code ID and restore the default Code IDs of all symbologies. Set PDF417 Code ID to “p”...
【Enter Setup】 Custom Suffix Enable/Disable Custom Suffix If custom suffix is enabled, you are allowed to append after the scanned data a user-defined suffix that cannot exceed 10 characters. For example, if the custom suffix is “AB” and the scanned data is “123”, the Host will receive “123AB”. **【Disable Custom Suffix】...
【Enter Setup】 Terminating Character Suffix Enable/Disable Terminating Character Suffix A terminating character such as carriage return (CR) or carriage return/line feed pair (CRLF) can only be used to mark the end of data, which means nothing can be added after it. **【Disable Terminating Character Suffix】...
【Enter Setup】 Set Terminating Character Suffix The scanner provides a shortcut for setting the terminating character suffix to CR (0x0D) or CRLF (0x0D,0x0A) by scanning the appropriate barcode below. 【Terminating Character CR (0x0D)】 【Terminating Character CRLF (0x0D,0x0A)】 To set a terminating character suffix, scan the Set Terminating Character Suffix barcode, the numeric barcodes corresponding to the hexadecimal value of a desired terminating character, and the Save barcode.
Page 131
5-Digit Add-On Code Disabled UPC-E UPC-E Enabled Check Digit Transmit 2-Digit Add-On Code Disabled 5-Digit Add-On Code Disabled Add-On Code Not required Extend to UPC-A Disabled System Character “0” Do not transmit UPC-A UPC-A Enabled Check Digit Transmit 2-Digit Add-On Code Disabled 5-Digit Add-On Code Disabled...
Page 132
Maximum Length Minimum Length No less than 6 Code 39 Code 39 Enabled Check Digit Verification Disabled Start/Stop Character Do not transmit Code 39 Full ASCII Enabled Maximum Length Minimum Length Codabar Codebar Enabled Check Digit Verification Disabled Start/Stop Character ABCD/ABCD format Uppercase Do not transmit...
Page 133
Check Digit Verification 1 Check Digit, MOD11 Maximum Length Minimum Length No less than 2 ISSN ISBN Disabled 2-Digit Add-On Code Disabled 5-Digit Add-On Code Disabled Add-On Code Not required ISBN ISBN Disabled ISBN Format ISBN-13 Industrial 25 Industrial 25 Enabled Check Digit Verification Disabled...
Page 134
Minimum Length No less than 2 PDF417 PDF417 Enabled PDF417 Twin Code Read single PDF417 only Transmission Order of Twin Code Order 1 Maximum Length Minimum Length QR Code QR Code Enabled QR Twin Code Read single QR only Micro QR Enabled Maximum Length 7089...
Appendix 5: Digit Barcodes After scanning numeric barcode(s), you need to scan the Save barcode to save the data. 【0】 【1】 【2】 【3】 【4】 【5】 【6】 【7】 【8】 【9】...
Appendix 6: Save/Cancel Barcodes After reading numeric barcode(s), you need to scan the Save barcode to save the data. If you scan the wrong digit(s), you can either scan the Cancel barcode and then start the configuration all over again, or scan the Delete the Last Digit barcode and then the correct digit, or scan the Delete All Digits barcode and then the digits you want.
Page 144
Headquarters Fujian Newland Auto-ID Tech. Co., Ltd. 3F, Building A, No.1, Rujiang West Rd., Mawei, Fuzhou, Fujian, China 350015 TEL: +86 - (0) 591-83979222 FAX: +86 - (0) 591-83979208 E-mail: marketing@nlscan.com WEB:www.nlscan.com Newland Europe BV Rolweg 25, 4104 AV Culemborg, The Netherlands...
