9.3

Checking Wiring and Settings

No COMS on the Serial side. If the Tx/Rx LEDs are not flashing rapidly then there is a COM issue. To fix
this problem, check the following:
•
Visual observations of LEDs on the ProtoNode. (Section 9.5)
•
Check baud rate, parity, data bits, stop bits.
•
Check Serial device address.
•
Verify wiring.
•
Verify device is connected to the same subnet as the ProtoNode.
No COMS on the Ethernet protocol. To fix this, check the following:
•
Visual observations of LEDs on the ProtoNode. (Section 9.5)
•
Check device address.
•
Verify wiring.
•
Verify device is connected to the same subnet as the ProtoNode.
•
Verify IP Address setting.
NOTE: If the problem still exists, a Diagnostic Capture needs to be taken and sent to support.
(Section 9.4)
