9.2
Viewing Diagnostic Information
•
Type the IP Address of the ProtoNode into the web browser or use the FieldServer Toolbox to
connect to the ProtoNode.
•
Click on Diagnostics and Debugging Button, then click on view, and then on connections.
•
If there are any errors showing on the Connection page, refer to Section
and settings.
Figure 24: Error Messages Screen
ProtoNode Start-up Guide
Troubleshooting
9.3
for the relevant wiring
26
