JR. GYMNASTICS KIP BAR
KIPBARHD
409033
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!
Cover photo may show optional equipment not supplied
with standard unit. For an Operator's Manual and Decal
Kit in French or Spanish Language, please see your dealer.
Advertisement
Table of Contents
Related Manuals for Titan Fitness KIPBARHD
Summary of Contents for Titan Fitness KIPBARHD
- Page 1 JR. GYMNASTICS KIP BAR KIPBARHD 409033 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it! Cover photo may show optional equipment not supplied with standard unit.
- Page 2 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION WOOD HANDLE ADJUSTABLE TUBE UPRIGHT CROSS FRAME BASE FRAME POP PIN THREADED KNOB WOOD SCREW BOLT M4-1.0 (10) COLT M10-1.5X24MM (11) FLAT WASHER M10 ALLEN KEY...
- Page 3 ASSEMBLY INSTRUCTIONS STEP 1: Place an UPRIGHT (3) over one end of the CROSS FRAME (4) and the middle of a BASE FRAME (5). STEP 2: Secure the UPRIGHT (3) by installing the THREADED KNOBS (7) and using the ALLEN KEY to install the BOLTS M10-1.5x24MM (10) and the FLAT WASHERS M10 (11).
- Page 4 STEP 3: Insert the WOOD HANDLE (1) into both ADJUSTABLE TUBES (2) and align the holes. STEP 4: Insert the ADJSUTABLE TUBE (2) into the UPRIGHT (3) and lock it in place with the POP PIN (6).
- Page 5 STEP 5: Install a BOLT M10-1.5x24MM (9) into both sides of each ADJUSTABLE TUBE (2). STEP 6: Install a WOOD SCREW (8) into the top and bottom of each ADJUSTBALE TUBE (2).
- Page 6 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 7 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2021 Titan Brands...
