DeviceNet Network Status LED
Solid Green
Flashing Green
Solid Red
Flashing Red
DeviceNet Module Status LED
Flashing Green
Solid Green
Solid Red
Flashing Red
© 2005 HMS Industrial Networks
State Summary
Online with
no errors
Online, no
communica-
tion
DeviceNet
interface fault
Connection
time-out
Table 7-2 DeviceNet Network Status LED States
State Summary
Initializing
or
Not config-
ured
Normal
Unrecover-
able major
fault
Recoverable
minor fault.
Table 7-3 DeviceNet Module Status LED States
Status and Diagnostics 7-2
Description
The Anybus-X is on the DeviceNet
network and all I/O connections are
running correctly.
The Anybus-X is on the DeviceNet
network and is not currently communi-
cating with any devices.
A major fault in the DeviceNet inter-
face has been detected. Possible causes
include Bus-off or duplicate MAC ID.
A connection with at least 1 slave
device has timed out.
Description
The module is initializing.
The DeviceNet network configuration
has not been configured and is cur-
rently using default values.
Normal operation.
A fault the requires user intervention
has been detected. Correct the problem
and reset the Anybus-X.
A fault that can be corrected and does
not require a Anybus-X reset has been
detected. This is typically a configu-
ration error.
