Specifications; Product Name - Intel IB840 User Manual

Specifications

Product Name

Form Factor
CPU Type
CPU Voltage
System Speed
CPU Frequency
Green /APM
CPU Socket
Chipset
BIOS
Cache
VGA
Primary LAN
Secondary LAN
Audio
Memory type
LPC I/O
RTC/CMOS
Battery
PS2 KB/Mouse
Local bus IDE
Serial ATA
PCI to ISA Bridge
ISA High drive
USB
IrDA
Disk On Chip
Watchdog Timer
Expansion slots
D-type
connector
Power
Connector
System Voltages
Board Size
Other Features
IB840
PICMG (full size CPU card)
Socket 478 (Intel Pentium 4 )
0.8375V~1.6V (VRD 10)
1.30G~3.2GHz
400 MHz /533MHz/800MHz
APM1.2
Socket 478
Intel 865G Chipset
GMCH: 82865G 932 pin FC-BGA
ICH5: 82801EB 460 pin MBGA
Award BIOS, support ACPI Function
128K/256K/512K Level 2 (CPU integrated)
Two selections:
1. Embedded 82865G, AGP 4X,support CRT interface only.
2. On board ATI Mobility M7/ M9 / M10 graphics
controller, embedded 32/64MB Frame buffer (DDR),
AGP 4X, support CRT, LVDS, TV-out / 2nd CRT.
Intel 82551QM LAN controller (10/100Mb)
Intel 82547EI (10/100/1000Mb) Gigabit LAN
ICH5 Built-in Sound controller + AC97 Codec ALC650, 2x6
12 pin header (Line-out, Line-in, MIC.). Supports 5.1
channels.
2 x DDR 2.5V PC266/333/400 DDR SDRAM (without ECC
Function) DIMM Module, Max. capacity - 2GB
Winbond 83627HF: IrDAx1 Parallel x1,
COM1(RS-232),COM2(RS-232/RS422/RS485), FDC
2.88MB (3 Mode Support), Hardware monitoring
ICH5 Built-in
Lithium Battery
Controller built in Winbond 83627HF
ICH5 built in, IDE1, IDE2 (Ultra DMA 33/66/100)
2 ports
ITE 8888
Supported by SN74ABT16245
4 ports, USB 2.0
Pin header
Supports up to 288MB capacity
Yes ( 256 segments : 0,1,2,...255 sec/min)
MicroAGP VGA socket for IBA120 and IBA110
PS/2 keyboard/mouse, VGA (CRT), RJ-45 x 2
ATX 12V
+5V, +12V, -12V, 5VSB
122 x 338 mm
Modem Wakeup, LAN Wakeup ,
