5

TECHNICAL DATA, SIGNALS, DIAGRAMS

5.1

Technical data

CUTTING / AUTO CUT with automatic voltage control
HF voltage waveform
Crest factor C, at R =500 ohms
L
Rated frequency
Maximum HF voltage at R
Dynamic internal impedance in the rated load range
Cutting quality
Consistancy of 4 coagulation effects
HF rated power
HF power limitation
Setting the HF power limitation
Display of HF power limitation
Precision of the HF power limitation
Automatic power control (PPS)
Activation of the cutting mode
HF connecting sockets
CUTTING / ENDO CUT
Applies only to ERBOTOM ICC 200 with Endo Cut
Automatically arc-triggered, fractionated cutting
Basic setting
SOFT COAGULATION
HF voltage waveform
Crest factor C, at R = 500 ohms
L
Rated frequency of the HF voltage
Peak value of the HF voltage
Constancy of the HF voltage
HF rated power
HF power limitation (P
HFmax.
Setting of the HF power limitation
Display of the HF power limitation
Precision of the HF power limitation
Activation of Soft coagulation
HF connecting sockets
FORCED COAGULATION
HF voltage waveform
Crest factor C, at R =500 ohms
L
Rated frequency of the HF voltage
Peak value of the HF voltage, Version 1
Peak value of the HF voltage, Version 2
Peak value of the HF voltage, Version 3
HF rated power
HF power limitation
Setting of the HF power limitation
Stability of the HF power
Display of the HF power limitation
Precision of the HF power limitation
Activation of the Forced coagulation
HF connecting sockets
=∞
L
)
unmodulated sinusoidal alternating voltage
C = 1.4 for all settings
330 kHz
600 Vp
0 ohms
4 coagulation effects selectable
automatically controlled
200 watts at R = 500 ohms
L
1 to 200 watts in 1 watt steps
via up/down keys
7-segment display, 3 decimal places
+/- 1 digit or +/- 15%
yes
via key or via pedal
1
t
t
= 50 ms, = 750 ms
on off
unmodulated sinusoidal alternating voltage
C = 1.4 for all setttings
330 kHz
max. 190 V p
automatically controlled up to P
120 watts at 125 ohms
from 1 watt to 120 watts in 1 watt steps
via up/down keys
7-segment display, 3 decimal places
+/- 1 digit or +/- 15%
via key or via pedal
1
pulse-modulated alternating current (ST generator)
C = 5 at 120 W , C = 11 at 5 W
max
1 MHz
max. 1300 Vp
max. 2300 Vp
max. 2300 Vp
120 watts at 350 ohms
from 1 watt to 120 watts in 1 watt steps
via up/down keys
see diagram Forc. Coag. power via R
7-segment display, 3 decimal places
+/- 1 digit or +/- 15%
via key or via pedal
1
5-1
HFmax.
max
L
