Johnson Controls TCSC Series Installation Operation & Maintenance page 28

SEE NOTE 4
SEE NOTE 5
AIR
B
SEE NOTE 5 SEE NOTE 4
AIR
D
PICV - 4 OR 8 GPM VALVE PACK
(LEFT HAND SHOWN)
(RIGHT HAND OPPOSITE)
UNIT SIZE COIL ROWS
1/2/3
07/10
4
1/2/3
15/20/23
4
1/2/3
35/45
[TCSB & TCSQ
ONLY]
4
28
THIS DRAWING CONTAINS PROPRIETARY DATA. UNAUTHORIZED DISCLOSURE,
REPRODUCTION, OR USE IS STRICTLY PROHIBITED WITHOUT WRITTEN PERMISSION.
MODEL TCSC SIZES 07-23
3/8" Coil Valve Package Connections
8 1/2"
RETURN (OUT)
216
12 1/8"
308
SEE NOTE 4
SUPPLY (IN)
PICV 2GPM VALVE PACK
(LEFT HAND SHOWN)
(RIGHT HAND OPPOSITE)
9"
RETURN (OUT)
229
12 1/8"
308
SEE NOTE 4
SUPPLY (IN)
A B
5-15/16" 13-1/4" 5-15/16"
[151] [337] [151]
5-15/16" 12-3/4" 5-15/16"
[151] [324] [151]
7-5/16" 13-1/4" 7-5/16"
[186] [337] [186]
7-5/16" 12-3/4" 7-5/16"
[186] [324] [186]
7-1/16" 13-1/4" 7-1/16"
[180] [337] [180]
7-1/16" 12-3/4" 7-1/16"
[180] [324] [180]
SUBMITTAL DRAWING
ALL DRAWINGS ARE SUBJECT TO CHANGE
DO NOT SCALE DRAWING
DIMENSIONS ARE IN INCH [MM] FORMAT
+/- 1/8 [3] UNLESS OTHERWISE NOTED
A
4"
102
SEE NOTE 6
C
4"
102
SEE NOTE 6
NOTES:
1. All dimensions are in inches [millimeters]
All dimensions may have 1/2 [13mm]
variation.
Metric values are soft conversion.
2. All drawings subject to change without
C D
notice.
3. Consult unit selection summary
13-7/8"
[353] for valve package components and
specifications. Valve package end point
13-3/8"
dimensions are fixed value,regardless of
[340]
selected valve package components.
4. Dimensions indicate space requirement
13-7/8"
[353]
for valve-package install. Additional
service space requirements depend on
13-3/8"
[340]
option selections.
5.Valve package support structure can be
13-7/8"
removed.
[353]
6. SS flexible hoses are available but not
13-3/8"
shown.
[340]
TITLE:
MODEL TCSB, TCSQ & TCSC 3/8" DIA, HW
COIL, VALVE PACKAGE CONNECTIONS
WITHOUT PRIOR NOTICE
DATE
4/29/2021
FORM 130.13-NOM8 (1021)
12"
304
8 3/4"
222
SEE NOTE 4
12"
304
8 3/4"
222
SEE NOTE 4
SHEET DRAWING NO
JOHNSON CONTROLS
PAGE 3 OF 3 10-80049-J
REV
C
