MODEL TCSC SIZES 07-23 WITH ELECTRIC HEAT
Drawings not for installation purposes. Refer to unit and size-specific
ADDITIONAL ELECTRICAL
ENCLOSURE SIDE ACCESS
2-1/2"
64
PRIMARY
AIR
FLOW
"A"
11"
279
OPTIONAL
VALVE PACKAGE
ACCESS
2-1/2"
64
"D"
2-1/2"
64
DRIP TRAY
REMOVAL
BOTTOM ACCESS
NOTES:
1. All dimensions in Inches [millimeters]. All dimensions
2. Left Hand unit shown, Right Hand unit opposite.
3. Standard Electrical Enclosure is integrated into unit side. Includes (4) knockouts on (2) sides. Provide
sufficient clearance to access electrical controls and comply with applicable codes and ordinances.
4. NEC clearance can be from the bottom or side of the unit. When using side access, 9" of bottom
clearance recommended to access optional electrical disconnect and EC motor control.
12
THIS DRAWING CONTAINS PROPRIETARY DATA. UNAUTHORIZED DISCLOSURE,

Service And Clearance Requirements

submittal drawings for installation.
"C"
INDUCED
AIR FLOW
"B"
TOP VIEW
OPTIONAL FILTER
REMOVAL
SIDE ACCESS
"A"
DISCHARGE END VIEW
±
1/4" [6mm].
SUBMITTAL DRAWING
ALL DRAWINGS ARE SUBJECT TO CHANGE
WITHOUT PRIOR NOTICE
DO NOT SCALE DRAWING
DIMENSIONS ARE IN INCH [MM] FORMAT
22-1/2"
572
2-1/2"
64
UNIT
SIZE
OPTIONAL FILTER
07&10 35-1/2"
REMOVAL
15,
SIDE ACCESS
20,23
2-1/2"
64
"E"
9"
229
10"
ELECTRICAL ENCLOSURE
254
BOTTOM ACCESS
DOOR (OPEN POSITION)
TITLE:
MODEL TCSC SIZES 07-23, ELECTRIC HEAT,
EXTERNAL SPACE REQUIREMENTS
DATE SHEET
FORM 130.13-NOM8 (1021)
ELECTRIC HEAT
SIDE ACCESS
"F"
AIR
FLOW
COOLING COIL
"A" "B"
# ROWS
8-1/2" 31"
2 - 4
[216] [787]
13" 36"
6 - 8
[330] [914]
"C" "D" "E" "F"
15" 15" 14"
[902] [381] [381] [356]
40-1/2" 18" 18" 17"
[1029] [457] [457] [432]
ADDITIONAL
ELECTRICAL
ENCLOSURE
SIDE ACCESS
