Valve Package Coil Connections - Johnson Controls TCSC Series Installation Operation & Maintenance

SEE NOTE 5
SEE NOTE 4
AIR
B
MOD/PROP 2-WAY VALVE PACK
(RIGHT HAND OPPOSITE)
SEE NOTE 5
SEE NOTE 4
AIR
D
MOD/PROP 3-WAY VALVE PACK
(LEFT HAND SHOWN)
(RIGHT HAND OPPOSITE)
COIL
UNIT SIZE
ROWS
1/2/3
07/10
4
1/2/3
15/20/23
4
1/2/3
35/45
[TCSB & TCSQ
ONLY]
4
26
THIS DRAWING CONTAINS PROPRIETARY DATA. UNAUTHORIZED DISCLOSURE,
REPRODUCTION, OR USE IS STRICTLY PROHIBITED WITHOUT WRITTEN PERMISSION.
MODEL TCSC SIZES 07-23
3/8" Coil Valve Package Connections
9 1/4"
RETURN (OUT)
235
11 1/2"
292
SEE NOTE 4
SUPPLY (IN)
(LEFT HAND SHOWN)
9 1/4"
RETURN (OUT)
235
11 1/2"
292
SEE NOTE 4
SUPPLY (IN)
A B C
5-15/16" 12-5/8" 5-15/16"
[151] [324] [151]
5-15/16" 12-1/4" 5-15/16"
[151] [311] [151]
7-5/16" 12-5/8" 7-5/16"
[186] [324] [186]
7-5/16" 12-1/4" 7-5/16"
[186] [311] [186]
7-1/16" 12-5/8" 7-1/16"
[180] [324] [180]
7-1/16" 12-1/4" 7-1/16"
[180] [311] [180]
SUBMITTAL DRAWING
ALL DRAWINGS ARE SUBJECT TO CHANGE
DO NOT SCALE DRAWING
DIMENSIONS ARE IN INCH [MM] FORMAT
+/- 1/8 [3] UNLESS OTHERWISE NOTED
A
4"
102
SEE NOTE 6
C
4"
102
SEE NOTE 6
NOTES:
1. All dimensions are in inches [millimeters]
All dimensions may have 1/2 [13mm]
variation.
Metric values are soft conversion.
2. All drawings subject to change without
notice.
D
3. Consult unit selection summary
12-7/8"
for valve package components and
[327]
specifications. Valve package end point
12-3/8"
dimensions are fixed value,regardless of
[314]
selected valve package components.
12-7/8"
4. Dimensions indicate space requirement
[327]
for valve-package install. Additional
12-3/8"
service space requirements depend on
[314]
option selections.
12-7/8"
5.Valve package support structure can be
[327]
removed.
6. SS flexible hoses are available but not
12-3/8"
shown.
[314]
TITLE:
MODEL TCSB, TCSQ & TCSC 3/8" DIA, HW
COIL, VALVE PACKAGE CONNECTIONS
WITHOUT PRIOR NOTICE
DATE
SHEET
4/29/2021
FORM 130.13-NOM8 (1021)
12"
304
8 3/4"
222
SEE NOTE 4
12"
303
8 3/4"
222
SEE NOTE 4
DRAWING NO
JOHNSON CONTROLS
PAGE 1 OF 3 10-80049-J
REV
C
