1/2" Hot Water Coil Connections, Two Row, Two Circuit
B
A
SUPPLY (IN)
NOTES:
1. All dimensions are in inches [millimeters]
2. All dimensions may vary in 1/2 [13mm].
Metric values are soft conversion.
3. All drawings are subject to change without notice.
4. Connection Size: 5/8 ODM (1/2" NOM.)
5. This sheet applies to two row two circuit only.
For multiple circuit coils refer sheet no 1.
For single circuit coils refer sheet no 2.
JOHNSON CONTROLS
MODEL TCSC SIZES 07-15
RETURN (OUT)
SIDE VIEW
LEFT HAND SHOWN
RIGHT HAND OPPOSITE
2 5/8"
68
FRONT VIEW
LEFT HAND SHOWN
RIGHT HAND OPPOSITE
SUBMITTAL DRAWING
ALL DRAWINGS ARE SUBJECT TO CHANGE
WITHOUT PRIOR NOTICE
DO NOT SCALE DRAWING
TWO ROW TWO CIRCUIT COILS ONLY
Coil
No. of
Unit Size
Rows
Circuits
7/10
2
2
15
2
2
TITLE:
MODEL TCSB, TCSQ & TCSC
HOT WATER,1/2" DIA COIL CONNECTIONS
DATE
SHEET
FORM 130.13-NOM8 (1021)
AIR
(OPTIONAL)
(1/2"
Coil)
A
B
5-3/4"
2-7/8"
[146]
[74]
1-1/2"
2-7/8"
[38]
[74]
25
DRAWING NO
REV
