Johnson Controls TCSC Series Installation Operation & Maintenance page 19

1/2" Chilled Water Coil Connections, 2-4 Rows
(OPTIONAL)
NOTES:
1. All dimensions are in inches [millimeters]
2. All dimensions may vary in 1/2 [13mm].
Metric values are soft conversion.
3. All drawings are subject to change without notice.
4. Connection Size: 5/8 ODM (1/2" NOM).
JOHNSON CONTROLS
THIS DRAWING CONTAINS PROPRIETARY DATA. UNAUTHORIZED DISCLOSURE,
REPRODUCTION, OR USE IS STRICTLY PROHIBITED WITHOUT WRITTEN PERMISSION.
THIS DRAWING CONTAINS PROPRIETARY DATA. UNAUTHORIZED DISCLOSURE,
MODEL TCSC SIZES 07-23
SIDE VIEW
LEFT HAND SHOWN
RIGHT HAND OPPOSITE
FRONT VIEW
LEFT HAND SHOWN
RIGHT HAND OPPOSITE
Unit Type Coil Rows
7/10
12/15/20/23
SUBMITTAL DRAWING SUBMITTAL DRAWING
ALL DRAWINGS ARE SUBJECT TO CHANGE ALL DRAWINGS ARE SUBJECT TO CHANGE
WITHOUT PRIOR NOTICE WITHOUT PRIOR NOTICE
DO NOT SCALE DRAWING DO NOT SCALE DRAWING
DIMENSIONS ARE IN INCH [MM] FORMAT DIMENSIONS ARE IN INCH [MM] FORMAT
FORM 130.13-NOM8 (1021)
B
C
RETURN(OUT)
A
4"
102
SUPPLY(IN)
1/2'' COILS
A B
5" 3 7/8"
2
[127] [98]
5" 3 7/8"
3
[127] [98]
5" 5"
4
[127] [127]
6" 3 7/8"
2
[152] [98]
6" 3 7/8"
3
[152] [98]
6" 5"
4
[152] [127]
TITLE: TITLE:
MODEL TCSC, CHILLED WATER, 1/2" DIA
COIL CONNECTIONS 2 - 4 ROWS
DATE DATE SHEET SHEET DRAWING NO DRAWING NO
AIR
C
2 3/4"
[70]
1 3/4"
[45]
1 3/4"
[45]
2 3/4"
[70]
1 3/4"
[45]
1 3/4"
[45]
REV REV 19
