Binks MX1212 Manual

12:1 Pump Systems for
Air Assist & Airless Finishing
SPECIFICATIONS
Ratio:
Maximum air inlet pressure:
Maximum fluid pressure:
Displacement per cycle:
Output @ 60 cycles/min:
Air consumption @ 20 cycles/min:
Maximimum recommended
continuous cycle rate:
Air inlet connection:
Air piston diameter:
Stroke length:
Fluid inlet connection:
Fluid outlet connection:
Wetted parts materials of
construction:
Sound level:
We reserve the right to change the specifications without prior notice.
© ITW INDUSTRIAL FINISHING 2010
MX1212
Patent 7,603,855
12:1
8 bar [116 psi]
96 bar [1390 psi]
72 cc [2.4 oz]
4.3 L/m [1.2 gal/m]
147 L PM [5.2 SCFM]
20 cycles/min
3/8" BSP(f) and 1/4" NPS(m)
85 mm [3.3 in]
75 mm [3.0 in]
3/4" NPS(m)
3/8" BSP(m) / 3/8" NPS(m)
Stainless Steel, Tungsten Carbide,
Hard Chrome, PTFE, Polyethylene,
Leather
96.2 dB
77-2925
