Binks M1-G HVLP Service Manual

SERVICE MANUAL
BINKS MODEL M1-G HVLP
GRAVITY FEED SPRAY GUN
6909-XXXX-X
The Binks M1-G HVLP Gravity Feed
Gun is a high quality sprayer that
produces fine finish for compliant and
non-compliant areas. A superbly bal-
anced forged aluminum body provides
you with extra comfort and control.
All components are machined and
finished to exacting tolerances and
only the best materials are used,
ensuring years of peak efficiency.
Simple to operate, the M1-G HVLP
provides exceptional finishes with
complex coatings such as primers,
base coats, clear coats, single stage
and waterborne compliant materials.
Additionally, specially designed air
and fluid nozzles enable the M1-G
HVLP to operate at more than 65%
transfer efficiency, in compliance with
air quality regulations as a high vol-
ume low pressure air spray gun.
The Binks M1-G HVLP Gravity
Feed Spray Gun includes a metal
paint cup with drip-proof cover.
To obtain optimum performance from
your new M1-G HVLP Gravity Feed
Spray Gun, read all instructions care-
fully.
NOTE
IMPORTANT REGULATORY NOTE regarding
the use of this product appears on page 9.
PACKAGE CONTENTS
Please note your Binks M1-G HVLP
Gravity Feed Spray Gun package
was shipped with the following con-
tents. If anything in the following
list is missing, call 1-800-992-4657
for a prompt shipment to you of the
missing item.
77-2650-R10.1 (2/2015)
Binks Model M1-G HVLP
GRAVITY FEED SPRAY GUN
6909-XXXX-X
2
1
Illustration Key
1. Air Nozzle Assembly
2. Gravity Feed Cup
3. Gun Body
4. Side Port Control
5. Fluid Control Knob
6. Air Connection 1/4" NPS(m)
PART
NO. DESCRIPTION
M1-G HVLP GRAVITY FEED SPRAY GUN ........ 1
54-4720 1 LITER GRAVITY FEED CUP ASSEMBLY.......... 1
SBBI-4-043 1 LITER CUP ASSEMBLY PART SHEET .............. 1
54-3871 GUNNERS MATE .............................................. 1
82-469 GUN BRUSH (ROUND)...................................... 1
192219 PLASTIC COATED GUN HOOK ........................ 1
OMX-88 CLEANING BRUSH (FLAT) ................................ 1
1 / 12
EN
3
4
5
6
QTY.
Replaces Part
