- Page 1 User Manual PCE-2550 Hardness Tester User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 28 December 2021 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Contents Safety notes ................... 1 Measuring principle ................2 Specifications ..................2 Technical specifications ....................2 Delivery scope........................5 Optional accessories ......................5 Device description ................6 Operation ....................8 Getting started........................8 Switching on the meter ..................... 9 Check before measurement ..................... 9 Calibration ........................10 Measurement ........................10 Save and delete ......................11... -
Page 3: Safety Notes
Safety notes Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the manual are excluded from our liability and not covered by our warranty. -
Page 4: Measuring Principle
Measuring principle An impact body of known weight is propelled against the measuring surface. The hardness value is calculated from the rebound velocity and the impact velocity at 1 mm distance from the measuring surface using the following formula: HL = 1000×VB/VA HL-- Hardness according to Leeb VB-- Rebound velocity VA-- Impact velocity... - Page 5 Measurement ranges according to material and hardness scale Material Steel and cast steel Scale Rockwell, Brinell, Vickers, Shore Measurement range HRC: 17.9 ... 68,5 Cast Steel HRB: 59.6 ... 99,6 HL / HV / HB / HRC / HS HRA: 59.1 ... 85,8 / HRB / HRA HB: 127 ...
- Page 6 Specifications D-type impact device Impact energy 11 Nmm / mJ Impact body mass 5.5 g Impact body Tungsten carbide 3 mm Application Suitable for most applications <500 HLD Test blocks ~600 HLD ~775 HLD Measurement range steel 81...654 HB Max. roughness of the measuring surface Peak-to-valley height R 10.0 µm Mean roughness R...
-
Page 7: Delivery Scope
Delivery scope 1 x hardness tester PCE-2550 1 x USB connection cable 1 x hardness test block 1 x cleaning brush 1 x support ring Ø14 mm 1 x carrying case 1 x user manual Optional accessories PCE-HAK, adaptor set, consisting of: HZ12.5-17... -
Page 8: Device Description
Device description OLED display Function keys Micro USB interface Impact device Impact body Support ring Clamping slide Trigger button © PCE Instruments... - Page 9 Function keys Function -On/off -In the menu: back -In measurement mode: save AVG measurement -Open menu -In the menu: Select, confirm, scroll through options -Cursor right/forward/down -Decrease numbers -Cursor left/back/up -increase numbers -In measurement mode: delete measurement Display (in measuring mode) Measured value / average value (AVG) Hardness scale Battery level indicator (no battery / charging via USB not possible)
-
Page 10: Operation
Operation Getting started General requirements for the material sample The surface temperature of the sample must be below 120 °C. The sample must meet the minimum thickness specified in the specifications. The surface to be tested should not be too uneven or rough. This could cause errors. The sample being measured should be metallic, smooth and free of grease. -
Page 11: Switching On The Meter
Requirements for the weight of the material sample For samples which are heavier than five kilogrammes and have a compact design, no support is necessary. Material samples with a weight of two to five kilogrammes but also heavier thin-walled samples should be stabilised by means of a fixing device. This is to prevent the sample from being deformed or displaced when touched. -
Page 12: Calibration
Calibration Before using the meter for the first time or if it has not been used for a long time, a calibration should be carried out using the Leeb hardness test block that comes with the meter. When switching on, press and hold ´and until calibration mode opens. -
Page 13: Save And Delete
Tensile strength measurement (Mpa σb) 5.5.2 To measure the tensile strength, select the mode for tensile strength in the "Test Set" menu under "Hard/σb": σb. Then set the desired material as well as the impact direction and proceed with the measurement as with the hardness measurement. -
Page 14: Menu Structure
The saved measurement data can be transferred to the PCE-2550 software via the USB interface. The software is available in several languages and can be downloaded free of charge from the PCE Instruments website: https://www.pce-instruments.com/english/download-win_4.htm Menu structure Test Set Measuring direction / Impact Direc. - Page 15 Scroll with the last key. measurement View From No. Change number Change position Display range selection Confirm Measurement data Transfer transfer to the PCE-2550 software Delete By No. Change number Deletion of Change position certain Confirm measurements Delete All Delete all measurements...
-
Page 16: Maintenance And Cleaning
Maintenance and cleaning Batteries (no rechargeable batteries) When the icon flashes, the batteries must be replaced. To do this, unscrew the cover at the back and remove the old batteries. Replace them with 2 new CR2016 button cells. Troubleshooting Problem Cause Solution Meter does not switch on... -
Page 17: Warranty
Warranty You can read our warranty terms in our General Business Terms which you can find here: https://www.pce-instruments.com/english/terms. Disposal For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament applies. Due to the contained pollutants, batteries must not be disposed of as household waste. They must be given to collection points designed for that purpose. - Page 18 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 26 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17 Tel.
