- Page 1 User Manual PCE-CLT 10 Electrical Tester User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 19 September 2019 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Contents Safety notes ................... 1 Characteristics ..................2 Technical specifications ..............2 Delivery contents .................. 2 Device description ................3 Operation ....................3 Preparation / inserting the batteries .................. 3 Turn on/off cable length tester ..................4 Main menu ........................4 Cable length measurement .................... -
Page 3: Safety Notes
Safety notes Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the manual are excluded from our liability and not covered by our warranty. -
Page 4: Characteristics
-10 ... 50°C / 14 ... 122°F Relative humidity 0 ... 80 % RH Delivery contents 1 x Cable fault meter PCE-CLT 10 2 x Test leads 2 x Crocodile clip 2 x AA battery 1.5V 1 x Transport bag 1 x User manual ©... -
Page 5: Device Description
Device description BNC socket – to measure cable length via Coax option RJ45 socket - to measure cable length via network option OK / measuring key Coax-netzwork switch key Set key key (up / increase value) key (down / decrease value) key (On/off / in menu: back) Operation Preparation / inserting the batteries... -
Page 6: Turn On/Off Cable Length Tester
Turn on/off cable length tester Press and hold the key for approx. 3 seconds to turn on the meter. To turn off the meter, press and hold the key for approx. 3 seconds again. Note: The meter has an automatic power off function to save battery power. The cable length meter will turn off automatically after 10 minutes of inactivity. - Page 7 Confirm your selection with the key. As soon as you have entered the mode for cable length measurements, the screen will look as follows after making a selection: Measuring mode for coaxial cables and Measuring mode for the length cables connected to the meter with a measurement of cables connected to the measuring adaptor RJ45 socket...
-
Page 8: Vop Library
6.4.2 Selecting the cable type To measure the cable length accurately, it is necessary to select the correct cable type and propagation velocity of the measuring signal (VOP) prior to the measurement. Press the key to be able to select the cable type from the database of the cable length tester with the key. - Page 9 As a last step, select your cable with the key. You can go back to the library by pressing the key. With the key, you can delete the current cable. To confirm the deletion, press . To cancel the deletion, press the key.
- Page 10 6.5.1 Pre-set cable types The cable types pre-set in the PCE-CLT 10 are: Network cable Coaxial cable Name Producer Name Producer CAT3UT HANWEI CW1308 CAT4UT HANWEI CFPE50 FOAMED CAT4ST DINTEK CFPE75 FOAMED CAT5UT DINTEK CSPE50 SOLLD CAT5ST SHIP CSPE75 SOLLD...
- Page 11 Under “length“, enter the length of the connected cable. You can select a value between 5 … 999 m. To change the value, first press the key to select the box. The value can then be changed with the keys .
- Page 12 6.5.3 Adding cables with known VOP values If the VOP value of the cable is known, you can add it without making a reference measurement. First enter the menu. Then select “Velocity of Propagation“ and “VOP Set“. In the “Name“ box, you can assign a name to the cable, for instance “NYM 1.5“. Up to six digits are possible.
-
Page 13: Showing The History
Showing the history To view the history of the cables last used, first enter the menu. Then select “History“. The cables last used will be displayed directly for your selection. You can select the desired cable with the keys. To confirm your selection, press Note: Measured values will not be saved. -
Page 14: Settings
Settings Enter the menu to make settings. Select “Setting“. In this menu, the following settings can be made: Menu Description Here you can set the unit. You can select metres “m“ or feet „ft“. Length Unit Time SET Here you can set the time. Format HH:MM Date SET Here you can set the date. -
Page 15: Warranty
Warranty You can read our warranty terms in our General Business Terms which you can find here: https://www.pce-instruments.com/english/terms. Disposal For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament applies. Due to the contained pollutants, batteries must not be disposed of as household waste. They must be given to collection points designed for that purpose. - Page 16 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17 Tel.
