ASSEMBLY MANUAL
All hardware on this set is specially coated
for corrosion resistance.
If non-Creative Playthings hardware is used,
it must be galvanized or stainless steel.
This product is intended for single
family home/residential use only and
not intended for use in any public
setting. Placement in any public
setting constitutes a misuse of this
product.
Creative Playthings
Please read the owner's manual before the
assembly of your play set. It provides
additional information on the care and use of
your play set.
You must carefully read the entire instruction
manual before proceeding with the assembly
or use of your new Playset.
Creative Playthings takes great care to design
its products with your child's safety in mind.
However, only with careful supervision
and proper safety instructions, can you be
assured of safe play time on any product
designed for children.
®
Advertisement
Table of Contents
Related Manuals for Creative Playthings NEWBURY
Summary of Contents for Creative Playthings NEWBURY
- Page 1 Playset. This product is intended for single Creative Playthings takes great care to design family home/residential use only and its products with your child’s safety in mind. not intended for use in any public However, only with careful supervision setting.
-
Page 2: Assembly Safety
• Until assembly is complete, DO NOT let your children use the Play Set. • Never fasten anything not approved by Creative Playthings to your Play Set. Accessories or items not ap- proved by Creative Playthings include; Dog runs, clothes lines, electrical devices, or bird feeders etc. - Page 3 • The Newbury gym has ground dimensions of 17' x 14'. • The Newbury gym requires a level ground surface of 29' x 29' for a Safe Play Area • Additional accessories may increase the size of the Safe Play Area.
-
Page 4: Hardware Bag Contents
17003-1609 Hex Bolt 1/4 x 4" 17119-1209 Truss Head Bolt 1/4 x 3" We have packaged more hardware than is required 17003-611 Hex Bolt 5/16 x 1-1/2" for assembly. NEWBURY Page 4 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20) -
Page 5: Pre Assembly Information
Assembly PRE ASSEMBLY INFORMATION CREATIVE PLAYTHINGS PLAYSETS USE A FEW STANDARD CONNECTIONS. BECOMING FAMILIAR WITH THESE CONNECTIONS WILL SIMPLIFY ASSEMBLY AND INSURE A SAFER PLAY PRODUCT FOR YOUR CHILDREN. Hex Bolt & Weld Nut Assembly Procedure: Assembly Layout: Align the holes in the parts to be fastened. Start preliminary tightening of bolt into weld nut by hand. - Page 6 PLAYSET VIEW NEWBURY Page 6 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20)
-
Page 7: Component View
COMPONENT VIEW Take inventory of all parts, making sure nothing is missing or defective. If you find that parts are missing or defective call the Creative Playthings Customer Service Department at 1-800-598-4997. 31682-102 Angle Brace 2 x 4 x 17-1/4"... -
Page 8: Maintenance Instructions
• Check structure twice monthly during usage for any evidence of deterioration. If upon inspection, hardware has sharp edges, rusted or structural pieces have signs of premature failure; replace them through Creative Playthings Customer Service. • Oil all metallic moving parts monthly during the usage season. - Page 9 Tent Pipes should face the ground. Make sure the other holes near the center are aligned as shown; closer to the top of the board. NEWBURY Page 9 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20)
- Page 10 Fasten two remaining Side Supports (AC) to the Swing End Assembly near the top using two 5/16 x 4-1/2" Hex Bolt Assem- blies each. NEWBURY Page 10 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20)
- Page 11 Sides. Attach the Platform Stringer using two 5/16 x 4-1/2" Lag Screws and Flat Washers as shown. Make sure the bottom edge of the stringer aligns with the bot- tom edge of the Platform Sides. NEWBURY Page 11 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20)
- Page 12 AD AD AD AD Posts. The gap between the boards will be approximately 1/4". Attach each Board to the Stringers using one #8 x 2" Screw in each hole. NEWBURY Page 12 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20)
- Page 13 Post and one wall of the center Tent Pipe. Secure the Tent Pipe to the Tent Post using one #8 x 1-5/8" Screw. Repeat with the other Tent Post. NEWBURY Page 13 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20)
- Page 14 The bolt must seat completely into the Climbing Rock, and not protrude more than a 1/8" past the end of the weld nut. Protruding bolts can be a hazard to users, replace any protruding bolts. NEWBURY Page 14 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20)
- Page 15 3/8" diameter holes through the support. Fasten the Access Ladder Brackets to the platform using 5/16 x 1-1/2" Hex Bolt Assemblies. Tighten all hardware. NEWBURY Page 15 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20)
- Page 16 1-5/8" Screws each as shown. Leave a maxi- mum of 2-1/2" between each Wall Slat and the adjacent post. Hold the Slat 1/2" above the Deck Boards. 1/2" gap below all Slats NEWBURY Page 16 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20)
- Page 17 THIS PRESENTS EXTREME DANGER TO YOUR CHILDREN. for clarity. Important: Set the rails of the Rock Climber into the ground so the Rope fastens as close to the ground as possible. NEWBURY Page 17 © Copyright 2015, Creative Playthings 19963-100 Rev C (05-20)
-
Page 18: Step 28 - Ground Stakes
Save all instruction sheets and receipts in case it becomes necessary to contact Creative Playthings for warranty service and/or part replacement. The warranty can be found in your Owner’s Manual. NEWBURY Page 18 ©...
