NORTHBRIDGE W/ TENT
ASSEMBLY MANUAL
All hardware on this set is specially coated
for corrosion resistance.
If non-Creative Playthings hardware is used,
it must be galvanized or stainless steel.
This product is intended for single
family home/residential use only and
not intended for use in any public
setting. Placement in any public
setting constitutes a misuse of this
product.
Creative Playthings
Please read the owner's manual before the
assembly of your play set. It provides
additional information on the care and use of
your play set.
You must carefully read the entire instruction
manual before proceeding with the assembly
or use of your new Playset.
Creative Playthings takes great care to design
its products with your child's safety in mind.
However, only with careful supervision
and proper safety instructions, can you be
assured of safe play time on any product
designed for children.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NORTHBRIDGE W/ TENT and is the answer not in the manual?

Questions and answers

Related Manuals for Creative Playthings NORTHBRIDGE W/ TENT

Summary of Contents for Creative Playthings NORTHBRIDGE W/ TENT

  • Page 1 Playset. This product is intended for single Creative Playthings takes great care to design family home/residential use only and its products with your child’s safety in mind. not intended for use in any public However, only with careful supervision setting.

  • Page 2: Assembly Safety

    • Until assembly is complete, DO NOT let your children use the Play Set. • Never fasten anything not approved by Creative Playthings to your Play Set. Accessories or items not ap- proved by Creative Playthings include; Dog runs, clothes lines, electrical devices, or bird feeders etc.
  • Page 3 (2 M) (2 M) Whichever is greater Landscape Timbers 6' from (2 M) play structure. A FALL ONTO A HARD SURFACE COULD RESULT IN SERIOUS INJURY. NORTHBRIDGE WITH TENT Page 3 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 4 1/4 x 1-1/2" Lag Screw Hex Bolt 3/8 x 6" 3/8 x 5-1/2" Lag Screw 1/4 x 1-1/2" Hex Bolt 3/8 x 8" Lag Screw Truncated to fit on page NORTHBRIDGE WITH TENT Page 4 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)

  • Page 5: Hardware Bags

    17001-103 Weld Nut 3/8" CREATIVE PLAYTHINGS PLAY SETS USE A FEW STANDARD CONNECTIONS. BECOME FAMILIAR WITH THESE CONNECTIONS TO EASE ASSEMBLY AND ENSURE A SAFER PLAY PRODUCT FOR YOUR CHILDREN. Hex Bolt & Weld Nut Assembly Procedure: Assembly Layout: Align the holes in the parts to be fastened.
  • Page 6 PLAYSET VIEW NORTHBRIDGE WITH TENT Page 6 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)

  • Page 7: Component View

    COMPONENT VIEW Take inventory of all parts, making sure nothing is missing or defective. If you find that parts are missing or defective call the Creative Playthings Customer Service Department at 1-800-598-4997. * Not visible in illustration on Page 6 35246-102 Rock Board 5/4 x 6 x 27-1/4"...

  • Page 8: Maintenance Instructions

    • Check structure twice monthly during usage for any evidence of deterioration. If upon inspection, hardware has sharp edges, rusted or structural pieces have signs of premature failure; replace them through Creative Playthings Customer Service. • Oil all metallic moving parts monthly during the usage season.

  • Page 9: Step 1 - Platform Frame

    Washer, threaded into one Weld Nut. 5/16 x 6" Hex Bolt 3/8 x 4-1/2" Hex Bolt 5/16 x 6" Hex Bolt 3/8 x 6" Hex Bolt Tent Roof Version NORTHBRIDGE WITH TENT Page 9 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 10 Weld Nuts are clear as it may be hard to access the Weld Nuts later. 3/8" Weld Nut NORTHBRIDGE WITH TENT Page 10 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 11 STEP 8 – Rope Base Rail: Fasten the Rope Base Rail (N) to the Step Leg as shown, using two 5/16 x 4-1/2" Hex Bolt Assemblies. 5/16 x 4-1/2" Hex Bolt NORTHBRIDGE WITH TENT Page 11 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 12 Fasten the Rock Base Rail (M) to the back left Leg as shown, using two 5/16 x 4-1/2" Hex Bolt Assemblies. 5/16 x 4-1/2" Hex Bolt NORTHBRIDGE WITH TENT Page 12 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 13 Ends using 3/8 x 8" Lag Screws and 3/8" Flat Washers. Tighten all fasteners securing the Beams to the Posts 3/8 x 8" Lag Screw NORTHBRIDGE WITH TENT Page 13 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)

  • Page 14: Step 16 - Side Supports

    5/16 x 4-1/2" Hex Bolt Assembly. Leave the fasteners very loose to ease insertion of the Steps. t h e 5/16 x 4-1/2" Hex Bolt NORTHBRIDGE WITH TENT Page 14 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 15 Rail using one 5/16 x 5" Hex Bolt Assembly. Important Note: Reverse the Hex Bolt As- sembly so the Weld Nut is on the outside of the gym. 5/16 x 4-1/2" Hex Bolt NORTHBRIDGE WITH TENT Page 15 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 16 End Deck Boards using #8 x 1-5/8" Screws in each small hole. Repeat with the remaining End Deck Boards at the other end of the platform, overhanging the Ladder Platform End 1/4" Overhang 1/4". NORTHBRIDGE WITH TENT Page 16 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)

  • Page 17: Step 26 - Hand Grips

    Grip. Drill and fasten the Hand Grip as above. Repeat with the remaining Grips on the other end of the gym on the front right Post and back right Leg. NORTHBRIDGE WITH TENT Page 17 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 18 Tent Post and one wall of the center Tent Pipe. Secure the Tent Pipe to the Tent Post using one #8 x 1-5/8" Screw. Repeat with the other Tent Post. NORTHBRIDGE WITH TENT Page 18 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 19 WARNING: AT NO TIME SHOULD THE BOTTOM END OF THE ROPE BE UNTIED OR LOOSE ENOUGH TO FORM A LOOP. THIS PRESENTS EXTREME DANGER TO YOUR CHILDREN. NORTHBRIDGE WITH TENT Page 19 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)

  • Page 20: Step 34 - Cargo Net

    Be sure there is a space of at least 9" between the top horizontal rope and the bottom of the Stair Platform End. Overhand Knot NORTHBRIDGE WITH TENT Page 20 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 21 Weld Nut in the framing member. Re-attach the Platform Board and Slide Mount and continue securing the Slide. NORTHBRIDGE WITH TENT Page 21 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
  • Page 22 Save all instructions and receipts in case it becomes necessary to contact Creative Play- things for warranty service and/or part replacement. The warranty can be found in your Owner’s Manual. NORTHBRIDGE WITH TENT Page 22 © Copyright 2016, Creative Playthings 19949-100 Rev C (05-18)
