MODEL PSRAL
ASSEMBLY MANUAL
If you have problems or questions about your Creative Playthings play set,
Contact Creative Playthings Customer Service at 1-800-598-4997 or
All hardware on this set is specially coated
for corrosion resistance.
If non-Creative Playthings hardware is used,
it must be galvanized or stainless steel.
This product is intended for single
family home/residential use only and
not intended for use in any public
setting. Placement in any public
setting constitutes a misuse of this
product.
DO NOT CALL THE RETAILER.
customerservice@creativeplaythings.com
™
Please read the owner's manual before the
assembly of your Play Set. it provides additional
information on the care and use of your Play Set.
You must carefully read the entire instruction man-
ual before proceeding with the assembly or use
of your new Play Set.
Creative Playthings takes great care to design its
products with your child's safety in mind. How-
ever, only with careful supervision and proper
safety instructions, can you be assured of safe
play time on any product designed for children.
Save these instructions for reference in case you
need to contact customer service.
By

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Playtime PSRAL and is the answer not in the manual?

Questions and answers

Related Manuals for Creative Playthings Playtime PSRAL

Summary of Contents for Creative Playthings Playtime PSRAL

  • Page 1 ™ MODEL PSRAL ASSEMBLY MANUAL If you have problems or questions about your Creative Playthings play set, DO NOT CALL THE RETAILER. Contact Creative Playthings Customer Service at 1-800-598-4997 or customerservice@creativeplaythings.com Please read the owner’s manual before the All hardware on this set is specially coated assembly of your Play Set.
  • Page 2 • Until assembly is complete, DO NOT let your children use the Play Set. • Never fasten anything not approved by Creative Playthings to your Play Set. Accessories or items not ap- proved by Creative Playthings include; Dog runs, clothes lines, electrical devices, or bird feeders etc.

  • Page 3: Safe Play Area

    (2 M) (2 M) Whichever is greater (4.27 M) Landscape Timbers 6' from (2 M) play structure. A FALL ONTO A HARD SURFACE COULD RESULT IN SERIOUS INJURY. MODEL PSRAL Page 3 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)

  • Page 4: Hardware Bag Contents

    Hex Bolt 1/4 x 2-1/2" 17036-1201 Lag Screw 1/4 x 3" 17003-1209 Hex Bolt 1/4 x 3" 17003-1409 Hex Bolt 1/4 x 3-1/2" 17003-1609 Hex Bolt 1/4 x 4" MODEL PSRAL Page 4 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)

  • Page 5: Pre Assembly Information

    PRE ASSEMBLY INFORMATION CREATIVE PLAYTHINGS Play SetS USE A FEW STANDARD CONNECTIONS. BECOMING FAMILIAR WITH THESE CONNECTIONS WILL SIMPLIFY ASSEMBLY AND INSURE A SAFER PLAY PRODUCT FOR YOUR CHILDREN. Hex Bolt & Weld Nut Assembly Procedure: Assembly Layout: Align the holes in the parts to be fastened. Start preliminary tightening of bolt into weld nut by hand.
  • Page 6 PLAY SET VIEW Items Packaged Separately: 60081-102 Playtime Swing Beam 8515-202 8 Ft. Wave Slide, Green AA934-204 2 Swings, 1 Trapeze MODEL PSRAL Page 6 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)

  • Page 7: Component View

    AO 1 33974-102 Safety Rail 5/4 x 4 x 41-1/2" AP 1 33971-102 Long Ladder Slat 1 x 4 x 18-3/4" * Not marked on Play Set View page. MODEL PSRAL Page 7 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)

  • Page 8: Maintenance Instructions

    • Check structure twice monthly during usage for any evidence of deterioration. If upon inspection, hardware has sharp edges, rusted or structural pieces have signs of premature failure; replace them through Creative Playthings Customer Service. • Oil all metallic moving parts monthly during the usage season.
  • Page 9 Fasten the other Sandbox End (AF) to the back of the Back Left and Back Right Posts in the same way. 2" Lag Screw in Bottom Holes MODEL PSRAL Page 9 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 10 Stringer. Fasten the Stringer (G) to the Platform Front and Platform Back using four #8 x 2-1/2" Screws as shown. 2-1/2" Screws MODEL PSRAL Page 10 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 11 1/4 x 2" Lag Screws in the bottom holes as indicated. Be sure to orient the board so the holes at the ends are closer to the top edge. MODEL PSRAL Page 11 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 12 Assemblies in in the top holes and two 1/4 x 2" Lag Screws in the bottom top holes holes as indicated. 2" Lag Screws in Bottom Holes MODEL PSRAL Page 12 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 13 Use 1/4 x 4" Hex Bolt Assemblies in the top holes and 1/4" x 2" Lag Screws with 1/4" Flat Washers in the bottom holes. 2" Lag Screws in Bottom Holes MODEL PSRAL Page 13 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 14 Drill 5/16" diameter holes through the holes in the Brackets and through the Platform Back. Secure the Brackets using 1/4 x 1" Hex Bolt Assemblies. 1/4 x 1" Hex Bolt 1/4 x 1-1/2" Hex Bolt MODEL PSRAL Page 14 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 15 Rafters on the assembled panel. Align the ends. Fasten Roof Boards to the Roof Rafters using 1/8" diam- eter pilot holes and #8 x 1-5/8" Screws as with the first Roof Panel. MODEL PSRAL Page 15 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 16 (AM) using one 1/4 x 1-1/2" Hex Bolt Assembly. Fasten each Rock Upright Bracket to the Platform Right using one 1/4 x 1-1/2" Hex Bolt Assembly. 1/4 x 1-1/2" Hex Bolt Assemblies MODEL PSRAL Page 16 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 17 Narrow Deck Board and Back Right Post. The gap between the Slats will be approximately 1-1/2". Use a level to ensure the Slats are Plumb #8 x 1-5/8" Screws in the bottom holes. MODEL PSRAL Page 17 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 18 Drill a pilot hole into the post at the other end of the Safety Rail. Fasten using one 1/4 x 2" Lag Screw and Flat Washer. 23" 1/4 x 2" Lag Screws using 3/16" dia. pilot MODEL PSRAL Page 18 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 19 Weld Nut with Short Weld Nuts in the Framing Member. Re-attach the Platform Board and continue securing the Slide. MODEL PSRAL Page 19 © Copyright 2014, Creative Playthings 19864-200 Rev C (12-18)
  • Page 20 Swing Set. Save all instruction sheets and receipts in case it becomes necessary to contact Creative Playthings for warranty service and/or part replacement. The warranty can be found in your Owner’s Manual. MODEL PSRAL Page 20 ©...
