Directed Directechs DS3+ Installation Manual page 9

Module
Conn./Pin Color Description
H2/16 Red/Blue (-) Valet Switch
H2/17 Black/White (-) E-Brake Input
H2/18 Orange/Black (+) Instant Alarm Input
H2/19 Blue (-) Trunk Trigger Input
H2/20 Green (-) Door Trigger Input
H2/21 Gray (-) Hood Switch Input [1]
H2/22 Violet/White (AC) Tach Input
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. Immo. Data Interrupt (vehicle side)
[4]
H3/2 Blue/Red Relay N.O. No Connection
H3/3 Blue Relay COM Immo. Data Interrupt (conn. side)
[4]
H3/4 White/Brown Relay N.C. Ignition Interrupt (vehicle side) -
(Without T-Harness Only) [5]
H3/5 White Relay COM. Ignition Interrupt (conn. side) -
(Without T-Harness Only) [5]
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. No Connection
H3/8 Lt. Green Relay COM. Accessory Interrupt (conn. side)
[5]
H3/9 Lt. Green/White Relay N.C. Accessory Interrupt (vehicle side)
[5]
H3/10 Black (-) Ground
H3/11 White Relay COM. Ignition Interrupt (conn. side) -
(Without T-Harness Only) [5]
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12V Input
H4/3 Pink/Black Flex Relay (pin 87a)
H4/4 Pink/White (+) Flex Relay Output
9 933.HK18 1.13.195.3 2020 Hyundai Santa Fe
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Connects To
Wire Location
Driver Kick, red 54 pin plug (EM11), pin 40
No Connection
Driver Kick, red 54 pin plug (EM11), pin 40
ICU Junction Block-Dash Fuse Box, rear, white 47 pin plug (G),
pin 1
ICU Junction Block-Dash Fuse Box, rear, white 47 pin plug (G),
pin 1
Ignition Switch, black 6 pin plug, pins 1 and 5
No Connection
ICU Junction Block-Dash Fuse Box, rear, white 47 pin plug (G),
pin 45
ICU Junction Block-Dash Fuse Box, rear, white 47 pin plug (G),
pin 45
ICU Junction Block-Dash Fuse Box, rear, white 47 pin plug (G),
pin 1
Ignition Switch, black 6 pin plug, pins 1 and 5
Connects To
Wire Location
No Connection
Ignition Switch, black 6 pin plug, pins 1 and 5
No Connection
No Connection
(+/-) Wire Color Connection
(+/-) Wire Color Connection
Data White/Orange or Black Mandatory
Data White/Orange or Black Remote Start
Only
Cut Gray/Orange Mandatory
Cut Gray/Orange Mandatory
+ Blue/Orange and White Mandatory
(15A)
Cut Pink Mandatory
Cut Pink Mandatory
(chassis ground) Mandatory
Cut Gray/Orange Mandatory
+ Blue/Orange and White Mandatory
(15A)
(+/-) Wire Color Connection
+ Blue/Orange and White Remote Start
Only
(15A)
