- Page 1 CDL-165HUB USB to HDMI Display Converter Operation Manual CDL-165HUB...
- Page 2 Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document.
- Page 3 Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 4: Table Of Contents
Table of Contents Introduction Applications Package Contents System Requirements Features Specifications Operation Controls and Functions Front Panel Back Panel Software Installation Install DisplayLink Software Using DisplayLink Manager Using DisplayLink Manager Using More DisplayLink manager Firmware Update Uninstall the Device Driver Connection and Installation Troubleshooting Acronyms... -
Page 5: Introduction
1. Introduction Today people are spending more of their time around technology, especially for entertainment purposes, and often encounter problems. People spend a lot of their watching Internet TV (HULU for instance is a popular source for internet TV and movies However when the Internet TV viewer requires a larger viewing screen for a more immersive experience they then have to go through the hassle of connecting multiple cables. -
Page 6: Features
Features Supports HDMI & VGA outputs 16/32-bit Color for high-quality images HD resolution up to 1920 x 1080 HDMI and RGB display connectivity EDID selection with switch for VGA or HDMI output Secure and easy to use ... -
Page 7: Operation Controls And Functions
7. Operation Controls and Functions The following sections describe the hardware components of the unit and include a step by step installation guide and other suggested settings. 7.1 Front Panel HDMI OUT AUDIO OUT VGA OUT HDMI OUT: Connect the HDMI output to the HDMI display. ①... -
Page 8: Software Installation
Note: These two USB ports cannot be connected to a USB extension hub, doing so will trigger the system to detect the external Hub and will cause a system failure. Before removing the USB device, the user must follow the USB devices hardware removal procedure. -
Page 9: Using Displaylink Manager
9. Using DisplayLink Manager Using DisplayLink Manager After the driver is installed, a utility (DisplayLink Manager) will automatically appear in the system tray. The utility allows you to quickly change the settings and resolution for DisplayLink Manager. Right click on the icon will bring out the context menu. - Page 10 Color Quality: Select the screen color quality (available only in extended mode). Screen Rotation: Rotate the screen on the additional monitor by 90, 180 or 270 degrees. Extend to: Reposition the extended screen to the top, bottom, left or ...
- Page 11 Extend: Set the DisplayLink Manager to Extended mode. Set as Main Monitor: Set the monitor to be the main monitor. Notebook Monitor off: Set the PC/notebook's monitor off. ...
- Page 12 Mirror: Set the DisplayLink Manager to Mirror mode. You can see the same desktop image on the additional monitor. Off: Disable the DisplayLink Manager on the system. Advanced: Opening the Display Properties will allow you to adjust the ...
-
Page 13: Using More Displaylink Manager
Using More DisplayLink manager You don ’ t have to install a new driver as long as you have completed the above installation process in advance. It will automatically define the ID of the new Display Link Manager and will list everything in the Display properties or the display manager menu. -
Page 14: Uninstall The Device Driver
10. Uninstall the Device Driver Follow the steps below to uninstall the Multi View driver. Step 1: Open the Control Panel: Start → Control Panel → Add or Remove Programs. Step 2: Select USB-VGA-HDMI DisplayLink Adapter and click Remove. Step 3: Click Yes to confirm the removal. Step 4: Click Yes to restart your computer. -
Page 15: Connection And Installation
11. Connection and Installation Keybord Mouse HDD Flash Mini USB Cable CDL-165HUB Monitor Amplifier Speaker TV/Monitor... -
Page 16: Troubleshooting
12. Troubleshooting Situation Check Point 1. Make sure you restart your computer after the driver installation. 2. Check all the connectors are plugged in correctly. 3. Make sure the USB port that you are using is The device driver has USB 2.0. -
Page 17: Acronyms
Acronyms Acronym Complete Term EDID Extended Display Identification Data HDMI High-Definition Multimedia Interface Video Graphics Array... - Page 20 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20100427 MPM-CDL165HUB...
