2.2

Required Equipment

The following equipment and documents are included in the EVM evaluation kit:
• Evaluation board (EVM)
• Mini-USB cable
• Power cable
The following equipment is not included in the EVM evaluation kit, but is required for evaluation of this
product:
• TSW14J57EVM or TSW14J56EVM data capture board and related items
• High-Speed Data Converter Pro software
• PC computer running Microsoft
• One low-noise signal generator for analog input. TI recommends the following generators:
– Keysight E8663D
– Rohde & Schwarz
• Bandpass filter for analog input signal (1910 MHz or desired frequency). The following filters are
recommended:
– Bandpass filter, greater than or equal to 60-dB harmonic attenuation, less than or equal to 5%
bandwidth, greater than 18-dBm power, less than 5-dB insertion loss
– Trilithic™ 5VH-series tunable BPF
– K&L Microwave™ BT-series tunable BPF
– TTE KC6 or KC7-series fixed BPF
• Signal-path cables, SMA or BNC (or both SMA and BNC)
By default, the ADCxxDJxx00EVM has an onboard clocking solution. A few small board modifications
enable external clocking. If external clocking is used, the following equipment is recommended.
• Two low-noise signal generators. TI recommends similar models to the analog input source.
• A bandpass filter for the DEVCLK input. TI recommends a filter similar to the analog-input path filter.
NOTE: The clock source used to drive the LMK04828 (labeled LMKCLK) must be equal in frequency
to the ADC sampling clock (labeled DEVCLK). The clock generators must be frequency-
locked using a common 10-MHz reference.
