10.4~23.8" IP69K Stainless
Intel® Celeron® Bay Trail-M N2930, 1.83 GHz
Quick Start Guide
For more information on this and
other Winmate products, please
visit our website at:
www.winmate.com
Version 1.2
Document Part No. 915211101030
Please read this instructions before operating the device and retain them for future reference.
P-Cap Panel PC
Model No. R10IB3S-SPT269
R15IB3S-SPC369
R19IB3S-SPM169
W22IB3S-SPA369
W24IB3S-SPA269
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winmate W24IB3S-SPA269
Summary of Contents for Winmate W24IB3S-SPA269
- Page 1 R19IB3S-SPM169 W22IB3S-SPA369 W24IB3S-SPA269 Quick Start Guide For more information on this and other Winmate products, please visit our website at: www.winmate.com Version 1.2 Document Part No. 915211101030 Please read this instructions before operating the device and retain them for future reference.
-
Page 2: Table Of Contents
3.3.1 VESA Mounting - 21 - 3.3.2 Yoke Mounting - 22 - ❹ SPECIFICATIONS - 23 - APPENDIX - 26 - Appendix A: Cleaning the Monitor - 26 - Appendix B: Winmate Software Development Kit - 27 - - 2 -... - Page 3 IP69K Stainless Panel PC Quick Start Guide Preface FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received ...
- Page 4 Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume no responsibility or liability for...
- Page 5 IP69K Stainless Panel PC Quick Start Guide Preface Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
- Page 6 IP69K Stainless Panel PC Quick Start Guide Preface Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory.
-
Page 7: Features
❶ INTRODUCTION Congratulations on purchasing Winmate® IP69K Stainless P-Cap Panel PC. Winmate flat stainless steel P-Cap panel PCs and display are designed for applications with high hygienic requirements. IP69K series is completely waterproof with IP69K level of protection allowing for easy cleaning and sterilization. -
Page 8: Package Content
IP69K Stainless Panel PC Quick Start Guide Introduction 1.2 Package Content Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Factory shipment list: Quick Start Guide Driver CD &... -
Page 9: Product Overview
IP69K Stainless Panel PC Quick Start Guide Getting Started 1.3 Product Overview This section contains mechanical drawing of the Panel PC. Notice that this is a simplified drawing and some components are not marked in detail. 1.3.1 Dimensions 10.4" Unit: mm Dimensions : 289 x 246 x 49.9 1.3.2 Dimensions 15"... -
Page 10: Dimensions 21.5
IP69K Stainless Panel PC Quick Start Guide Getting Started 1.3.3 Dimensions 19” Unit: mm Dimensions : 467.4 x 392 x 56.6 1.3.4 Dimensions 21.5” Unit: mm Dimensions : 541 x 337 x 53 - 10 -... -
Page 11: Physical Buttons And Led Indicators
IP69K Stainless Panel PC Quick Start Guide Getting Started 1.3.5 Dimensions 23.8” Unit: mm Dimensions : 620 x 390 x 60 1.4 Physical Buttons and LED Indicators Physical buttons and LED indicators located on the rear side of the Panel PC. Physical Buttons Icon Button... -
Page 12: Connectors
IP69K Stainless Panel PC Quick Start Guide Getting Started LED Indicators LED Type Status Description Power is on Power is off Storage activity Blinking (Data is being read or written) System is idle 1.5 Connectors IP69K Stainless P-Cap Panel PC has M12 type connectors with protection cap and air venting valve. -
Page 13: ❷ Getting Started
IP69K Stainless Panel PC Quick Start Guide Getting Started ❷ GETTING STARTED 2.1 Turning On Follow the following steps to turn on your device: 1. Connect the AC adapter to the DC-in jack connector located on the back side of the Panel PC. 2. -
Page 14: How To Enable Watchdog
To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. Refer to the User Manual for more details. To enable watchdog in Watchdog AP follow the instructions below: 1. -
Page 15: Turning Off Your Device
IP69K Stainless Panel PC Quick Start Guide Getting Started Settings Description The system automaticity restarts when this Watchdog Countdown Time countdown time reaches zero. Default: 10 min To set a cycle time to automatically reset Periodically Feed Time watchdog timer. Default: 9 min Enable / Disable Enable or disable watchdog. -
Page 16: ❸ Installation
IP69K Stainless Panel PC Quick Start Guide Installation ❸ INSTALLATION 3.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. -
Page 17: Connector Pin Assignments
IP69K Stainless Panel PC Quick Start Guide Installation 3.2 Connector Pin Assignments This Panel PC is equipped with four M12 type connectors which are waterproof. Use only the cables that are included in the package. The pin assignments of the cables are as follows. -
Page 18: Serial Cable
IP69K Stainless Panel PC Quick Start Guide Installation 3.2.2 Serial Cable The IP69K Stainless P-Cap Panel PC has M12 type serial port connector. Use serial cable to connect serial interfaces. - 18 -... -
Page 19: Ethernet Cable
IP69K Stainless Panel PC Quick Start Guide Installation 3.2.3 Ethernet Cable The IP69K Stainless P-Cap Panel PC has M12 type Ethernet connector. Use Ethernet cable to connect the Panel PC to the Internet. - 19 -... -
Page 20: Usb 2.0 Cable
IP69K Stainless Panel PC Quick Start Guide Installation 3.2.4 USB 2.0 Cable The IP69K Stainless P-Cap Panel PC has M12 type USB 2.0 connector. Use USB 2.0 cable to connect external devices such as mouse or keyboard to the Panel PC. - 20 -... -
Page 21: Mounting
3.3.1 VESA Mounting The Panel PC has VESA mount holes on the rear side. Follow instructions below to mount the unit with VESA Mount bracket (not supplied by Winmate). Size VESA Plate Screw 10.4”, 15”, 19”... -
Page 22: Yoke Mounting
Quick Start Guide Installation 3.3.2 Yoke Mounting Yoke Mount solution allows installing the Panel PC with the bracket (not supplied by Winmate). Mounting instruction: 1. Place the Panel PC on the bracket stand, aiming screw holes for each other. 2. Secure screws to fix the device upon the bracket stand. -
Page 23: ❹ Specifications
IP69K Stainless Panel PC Quick Start Guide Specifications ❹ SPECIFICATIONS Hardware Specifications Model Name R10IB3S- R15IB3S- R19IB3S- W22IB3S- W24IB3S- SPT269 SPC369 SPM169 SPA369 SPA269 Display 10.4” 15” 19” 21.5” Size 23.8” Resolution 1024 x 768 1024 x 768 1280 x 1024 1920 x 1080 1920 x 1080 Brightness... - Page 24 IP69K Stainless Panel PC Quick Start Guide Specifications Model Name W24IB3S- R10IB3S- R15IB3S- R19IB3S- W22IB3S- SPA269 SPT269 SPC369 SPM169 SPA369 6 x USB2.0 6 x USB2.0 6 x USB2.0 6 x USB2.0 6 x USB2.0 (4 x (4 x USB (4 x USB (4 x USB (4 x USB...
- Page 25 IP69K Stainless Panel PC Quick Start Guide Specifications Order Information Panel PC SODIMM DDR3L Max Windows 10 IoT Enterprise Windows Embedded 8.1 Industry Pro Windows Embedded 8 Standard Windows Embedded 7 Standard Storage Mini PCIe SSD Touch Glass - 25 -...
-
Page 26: Appendix
IP69K Stainless Panel PC Quick Start Guide Appendix APPENDIX Appendix A: Cleaning the Monitor NOTE: The IP69K Stainless Panel PCs withstand regular intense cleaning and could hold up against steam and high-pressure water. The devices are able to sustain water temperatures up to 80°C and a water jets. -
Page 27: Appendix B: Winmate Software Development Kit
IP69K Stainless Panel PC Quick Start Guide Appendix Appendix B: Winmate Software Development Kit Winmate provides the following SDK and Utilities for the IP69K Flat Stainless P-Cap Panel PC. Item File Type Description Watchdog SDK Utility Watchdog Utility To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. - Page 28 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw www.winmate.com...
