Qtanium200 wiring – Trailer installation
The Qtanium200 when installed as a standard trailer tracking product only needs connections for power and ground.
Wire Color
Red
White
Black
The following wires will not be used for standard trailer asset tracking and should be taped off to prevent accidental triggering.
Wire Color
Blue
Orange
Green
Brown
Yellow
Green/Black
Blue/Black
White/Blue
Pink
4
Function
+12/24V
Connect to the positive post on the asset's battery or
another suitable permanent power supply source. This
connection must be fused (3 Amp).
Ignition Connect to same power connection as the Red wire. This
connection must be fused (3 Amp) separately.
Ground Battery Negative or Asset chassis connection.
Function
DI-1 Digital Input 1
DI-2 Digital Input 2
DO-1 Digital Output 1
DO-2 Digital Output 2
N/A Reserved
TxD RS232 Output
RxD RS232 Input
N/A Reserved
N/A Reserved
Description
Description
