Poke & Wrap power connection method
22
The recommended method of connecting the wires is by
soldering. As an alternative the connection can be made using
the Poke & Wrap method. This is only appropriate when the
connection is made inside the cab or an area that is completely
weatherproof.
Strip – Using wire strippers remove approximately ¾" of
Strip
insulation from the source wire. Also strip approximately 1" of
insulation from the fused Qtanium200 wire.
Divide – Using a tool with a point divide the source wires down
the middle.
Poke – Insert the fused wires stripped portion through the
middle.
Twist – Twist the fused wire around the source wire, 4-6 times
is recommended.
Divide
Lock – Now bend the fused wire back onto the wrapped
section. This helps ton act as a lock for this connection.
Secure – Apply high quality electrical tape to isolate your
connection. You should also add a zip-tie over the connection
to act as a tamper seal and makes sure the connection stays
for the life of the installation.
Poke
Twist
Lock
Secure
