TELETRAC NAVMAN Qtanium200 Installation Manual page 17

Power connections rear distribution block
You will need to gain access to run the Qtanium200
wiring into the power distribution. You should always use
the provided waterproof connectors already on the
distribution block. You will simply loosen one of the
connectors and run the Qtanium wires through with the
factory wires, and reattach the connector.
Power connections at the rear distribution block are the
same color wires as they are at the 7-way. The power
connection should be made to the ABS power which is
the blue wire, if the trailer does not have ABS you will
connect to the tail/running lights wire which is brown.
* You will not connect to both, connecting to
both will damage the trailer and possibly the
truck only one (1) power source is needed.
The ground connection will be made to the trailers white
wire.
Do note that even though this power distribution block is
a waterproof enclosure you must use the provided
shrinkable ring terminals.
17
