- Page 1 BRUTE FEED BUNKS ™ Brute Feed Bunks ™ All Rights Reserved. Reproduction SKU# DIMENSIONS is prohibited without permission. 108265 27" W x 24' L Revision date: 09.03.08...
-
Page 2: Required Tools
BRUTE FEED BUNKS ™ REQUIRED TOOLS The following list identifies the main tools needed to assemble the feed bunk. Additional tools may be needed. • Tape measure or measuring device • Marker READ THIS DOCUMENT BEFORE YOU • Variable speed drill and impact driver (cordless with BEGIN TO ASSEMBLE THE FEED BUNK. - Page 3 BRUTE FEED BUNKS ™ The following graphics and photos will help you identify the different parts of the feed bunk. Square Tube 1.5" x 1.5" SKU# Cut Length Quantity FA4482B 100441 104636 S15P010 1.5" x 1.5" x 10" Tek Screw Nut Setter Corner Bracket S15P014 1.5"...
- Page 4 BRUTE FEED BUNKS ™ Before assembling the feed bunk, layout and measure the 1.5" x1.5" square tube lengths to verify that you have all the correct tubes. Gather six (6) 96" tubes and two (2) 24" tubes. Assemble as shown below using corner brackets, 3-way fittings and Tek screws.
- Page 5 BRUTE FEED BUNKS ™ Gather four (4) 15" tubes and four (4) 14" tubes. Attach the 15" tubes to the corner brackets and the 14" tubes to the 3-way fittings as shown below. 15" 15" tube tube 14" tube 14" tube 14"...
- Page 6 BRUTE FEED BUNKS ™ Gather the two (2) PolyMax® end panels and place one at each end on the inside of the frame. Align a 23" length of aluminum strap across the top of the end segment. Using Tek screws, secure the aluminum strap and end panel to the top tube as shown below.
- Page 7 BRUTE FEED BUNKS ™ Gather six (6) one-way plates (#104624), two (2) 92" lengths of square tube, one (1) 96" length of square tube, four (4) 10" lengths of square tube and two (2) 4-way fittings (#104627). Complete the following steps inside the frame for easier assembly. Slide a 92"...
- Page 8 BRUTE FEED BUNKS ™ Place the 48" x 285" length of PolyMax® lining inside the bunk frame. Using three (3) 88" lengths of aluminum strap, secure one side edge of the PolyMax® along the top tube on the inside using Tek screws spaced at 12".
- Page 9 BRUTE FEED BUNKS ™ Gather four (4) one-way plates (#104624) and two (2) 23" lengths of square tube. Slide a plate onto each end of the tubes. Do not attach yet. Slide the assembled pieces into the center of the frame as shown below. Verify that the plates are over the end panels and secure to the top tube with Tek screws.
