Sunny SF-B1735 User Manual

44 lbs flywheel belt drive commercial indoor cycling bike
Hide thumbs Also See for SF-B1735:
Table of Contents

Advertisement

Quick Links

Download this manual
44 LBS FLYWHEEL BELT DRIVE
COMMERCIAL INDOOR CYCLING
BIKE
SF-B1735
USER MANUAL
IMPORTANT! Please retain owner's manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US: support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-B1735 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunny SF-B1735

Summary of Contents for Sunny SF-B1735

  • Page 1 44 LBS FLYWHEEL BELT DRIVE COMMERCIAL INDOOR CYCLING BIKE SF-B1735 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US: support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained, and used properly.

  • Page 3: Exploded Diagram

    EXPLODED DIAGRAM 1...

  • Page 4: Hardware Package

    EXPLODED DIAGRAM 2 HARDWARE PACKAGE...

  • Page 5: Parts List

    PARTS LIST Description Spec. Description Spec. QTY. Main Frame Foot Pad Front Stabilizer Tension Control Knob Rear Stabilizer Cow Leather Pad Seat Post EVA Pad Seat Slider Tube Bushing Handlebar T Shape Knob 1 Adjusting Screw T Shape Knob 2 Shipping Front Tube Pedal Shipping Rear Tube...
  • Page 6 Description Spec. QTY. Description Spec. QTY. M12*1*H6*S19 Computer E01a Computer Wire a M8*H7.5*S13 E01b Computer Wire b M8*H5.5*S14 Handle Pulse Wire D28L/R Nylon Nut 9/16"-20*H8*S19 Sensor Bolt M8*16 *S6 Trunk Wire Screw ST4.2*19 Sensor Wire Bolt M10*16*S6 Handle Pulse Sensor Magnetic Ordering Replacement Parts (U.S.
  • Page 7 ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 1: Unscrew the 4 Bolts (No. D04) with Allen Wrench (No. B17) and remove the 4 Flat Washers (No.
  • Page 8 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 3: WARNING! Read instructions carefully improper assembly cause permanent damage to your bike. Remove the preassembled 2 Bolts (No. D01) and 2 Flat Washers (No.
  • Page 9 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 4: Loosen and pull out the [seat] T Shape Knob 2 (No. C15). Insert the Seat Post (No. A04) into the tube located on the back of the Main Frame (No.
  • Page 10 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 6: Attach Computer (No. E01) onto the Computer Bracket (No. C18) located on the Handlebar (No.
  • Page 11 ADJUSTMENTS GUIDE ADJUSTING THE HEIGHT AND BALANCE In order to achieve a smooth and comfortable ride, you must ensure that the stability of the bike is secured. If you notice that the bike is unbalanced during use, you should adjust the Foot Pads (No.
  • Page 12 PEDAL STRAP ADJUSTMENT Your feet should be secured in the toe clips during exercise. Place your feet as far forward into the toe clips as you can. With your feet in place, turn the crank to bring one foot to within arm’s reach, grasp the pedal strap and pull it upward to tighten the toe clip cage.
  • Page 13 REMOVING THE CRANK ARM TO REMOVE THE CRANK ARM Unscrew 2 Bolts (No. D29) counter-clockwise with the Allen Wrench (No. B17). Remove the 2 Bolts (No. D29) and pull out the Left & Right Crank Arms (No. B03L/R). NOTE: The hexagonal hole on the middle axle and the crank arm should be aligned when assembling.
  • Page 14 SPD TECHNICAL SERVICE INSTRUCTIONS Caution! Before use, read these instructions carefully.  Practice engaging and disengaging from the pedals several times in a stationary position before riding.  Before using, lubricate the concave area of the clip.  Keep the cleat and pedal clean to ensure proper usage. ...

  • Page 15: Exercise Computer

    EXERCISE COMPUTER FUNCTION BUTTONS MODE: Press to select the function displayed or enter value during setting mode. Press and hold for 2 seconds to enter the RACE mode interface during STOP mode. SET: To set up the target value of TARGET, TIME, DIST, CAL. Press the button and hold for 2 seconds to speed up the increment during stop mode.
  • Page 16 1. TARGET: the preset CADENCE. 2. In STOP mode, press SET key to enter the TARGET setting in STOP mode. Press SET to increase the CADENCE five at a time. The setting change is 15 →20→ ……110→115→120→15 →20→……→115→120→ 15 →20→ …… 3.

  • Page 17: Maintenance Instructions

    MAINTENANCE INSTRUCTIONS This is general information for daily, weekly and monthly maintenance to be performed on your bike. DAILY MAINTENANCE MONTHLY MAINTENANCE After each exercise session, wipe down all the 1. Check if all hardware is secure, such as: water equipment: seat, frame, and handlebars.
