Specifications (Cont.)
I/O Interface
• Display: VGA
• USB: 3 USB2.0 (2 in front, 1 type-A onboard for software
key), 1 USB3.0 (in rear)
• PS/2: 1
Watchdog Timer
• Programmable 1~255 sec/min
Power Supply
• Output Rating: AC 250W, ATX
• Input Voltage: 100 VAC ~ 240 VAC
Cooling
• System Fan: 2 (6cm / 27.7 CFM)
• Air Filter: Yes
Environment
• Operating Temperature: 0 ~ 40 °C (32 ~ 104 °F)
• Non-operating Temperature: -20 ~ 60°C (-4 ~ 140 °F)
• Operating Humidity: 10 ~ 85% @ 40 °C, non-condensing
• Non-operating Humidity: 10 ~ 95% @ 40 °C, non-
condensing

Physical Characteristics

• Dimension (WxHxD): 232 x 90 x 232 mm

Jumpers and Connectors

The board has a number of jumpers that allow you to con-
figure your system to suit your application. The table below
lists the function of each of the jumpers and connectors.
Connectors
Label Function
LPT1 Parallel port, supports SPP/EPP/ECP mode
LAN1 Intel I219V
LAN2 Intel I211AT
VGA1 VGA connector
KBMS1 External keyboard/mouse connector
COM12 Box header for RS-232*2
HDD LED, power LED, SNMP SM_Bus,
FP1
reset, power on/off
JCASE1 Case open
CPUFAN1 CPU FAN connector (4-pin)
LANLED1 LAN1/2 LED connector
HDAUD1 HD audio extension module connector
USB1 USB port 1 (USB 3.0 port)
USB23 USB port 2, 3 (USB 3.0 port)
USB45 USB port 4, 5 (USB 2.0)
2 AIMC-3422 Startup Manual
Jumpers and Connectors
USB67 USB port 6, 7 (USB 2.0)
USB89 USB port 8, 9 (USB 2.0)
USB11 Type A connector on board (USB 2.0)
SATA0 Serial ATA1 (SATA 3.0)
SATA1 Serial ATA2 (SATA 3.0)
SATA2 Serial ATA3 (SATA 3.0)
SATA3 Serial ATA4
CPU1 CPU Socket
DIMMA1 Memory connector channel A
DIMMB1 Memory connector channel B
GPIO1 GPIO pin header
LPC1 Low pin count module expansion pin-header
PWR1 12 V, 5 V power connector
DVI1
DVI connector
Display pin header to stack board (Display
DP1
type depends on optional stack board)
EXPCIE1 mini PCIe pin header to stack board
MINIPCIE
M-SATA (default) or mini-PCIe connector
MSATA
Jumpers
Label Function
JCMOS1 CMOS clear
Hardware monitor alarm+watchdog
JWDT1+JOBS1
timer output selection
JME1 Enable ME
JCMOS1: Clear CMOS
Closed Pins Result
1-2 Keep CMOS (Default)
2-3 Clear CMOS
(Cont.)
