IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
B.
C.
Side Panel
Side Panel
1 pc.
1 pc.
H.
Back Panel
2 pcs.
M3x15
Magnet
Wood Screw
2 pcs.
4 pcs. (+1 extra)
Carton 5170 691 is also needed for assembly.
-
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8" Drill Bit
Home Styles Customer Service: www.homestylesfurniture.com,
servicedesk@homestylesfurniture.com,
5170 692
-
Pantry
D.
Side Panel
1 pc.
I.
Back Panel
2 pcs.
M3x30
Wood Screw (long)
6 pcs. (+1 extra)
E.
Side Panel
1 pc.
J.
Front Rail
3 pcs.
K.
O.
Back Rail
Door
4 pcs.
2 pcs.
M3x16
Wood Screw
for Upright
Adjustable Pin
4 pcs. (+1 extra)
16 pcs. (+1 extra)
888-680-7460, 877-831-0319
F.
G.
Upright
Upright
1 pc.
1 pc.
P.
Door
2 pcs.
M4x25
Machine Screw
7 pcs.
Knob
7 pcs.
Advertisement
Table of Contents
Related Manuals for Home Styles 5170 692
Summary of Contents for Home Styles 5170 692
- Page 1 4 pcs. (+1 extra) 16 pcs. (+1 extra) 7 pcs. 7 pcs. Carton 5170 691 is also needed for assembly. Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8” Drill Bit Home Styles Customer Service: www.homestylesfurniture.com, servicedesk@homestylesfurniture.com, 888-680-7460, 877-831-0319...
- Page 2 Assembly Instructions 2/7 IMPORTANT Ÿ Use a soft cloth between these parts and the floor. Ÿ Do not use power tools above 8 volts to assemble. Ÿ The unit must be level to work properly. Use the included adjustable levelers to level. STEP 1 Attach Back Rail (K) to Side Panel (B), then flip Lock.
- Page 3 Assembly Instructions 3/7 STEP 3 Lock Turn unit to its upright position. Attach Top (A) to unit, then flip Locks. STEP 4 Attach Back Rail (K) to Magnet Side Panel (D), then flip Lock. Attach Back Panels (I), Upright (G) Wood Screw (long) and Back Rail (K) to unit, then flip Lock.
- Page 4 Assembly Instructions 4/7 Lock STEP 6 Attach unit to Base (M), then flip Locks. Attach Top (L) to unit, then flip Locks. Adjustable Pin STEP 7 Attach unit from Step 3 to unit from Step 6, then flip Locks. Insert Adjustable Pins into side panels at desired level.
- Page 5 Assembly Instructions 5/7 Drawer (Q) STEP 8 Attach Drawer Sides (Q3) and (Q4) to Drawer Back (Q2), then flip Locks. (See Figures 5 and 6) Lock Figure 5 Figure 6 STEP 9 Insert Drawer Bottom (Q5) into groove. Attach Drawer Front (Q1) to unit, then flip Locks. Machine Screw Lock STEP 10...
- Page 6 Assembly Instructions 6/7 STEP 11 Level unit by adjusting the adjustable levelers on bottom of unit. (See Figure 7) Figure 7 Attach Doors (O) and (P) to unit by sliding door hinges into side panel hinges. (See Figure 8) Attach Knobs to Doors (O) and (P) with Machine Screws.
- Page 7 Assembly Instructions 7/7 IMPORTANT Ÿ To help reduce the risk of the unit tipping over, the Tipover Restraint must be installed following these instructions exactly. STEP 13 Anchor in wall Wall Screw Pre-drilled hole Bracket Place unit at desired location. on wall at top of unit 3/8”...
- Page 8 Buff with a dry clean cloth. Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized retail affiliate, Home Styles is under no obligation to provide replacement parts.
