Side chair

Advertisement

88 5134 80
Concrete Chic
Side Chair
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.

Part List

A.
Seat
1 Pc.
B.
Leg
1 Pc.

Hardware List

Hex Wrench
1 Pc.
Small Hex Wrench
1 Pc.
Tools required for assembly : Phillips screwdriver
D.
Stretcher
1 Pc.
C.
Leg
1 Pc.
Head Cap Bolt
(short)
2 Pcs. (+1 extra)
Wood Screw
6 Pcs. (+1 extra)
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
E.
Stretcher
1 Pc.
F.
Stretcher
1 Pc.
G.
Back Frame
1 Pc.
Head Cap Bolt
(middle)
4 Pcs. (+1 extra)
Head Cap Bolt
(long)
4 Pcs. (+1 extra)
Spring Washer
10 Pcs. (+1 extra)
Flat Washer
10 Pcs. (+1 extra)
