Round Table
(Black & Cottage Oak)
Important NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
PART LIST
A.
Table Top
1 pc.
HARDWARE LIST
Small
Hex Wrench
1 pc.
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
Connector Panel
Key Wrench
1 pc.
Hex Wrench
1 pc.
servicedesk@homestyles-furniture.com
B.
Post
1 pc.
1 pc.
Flat
Washer
16 pcs. (+ 1 extra)
Spring
Washer
16 pcs. (+1 extra)
C.
4 pcs.
Nut
12 pcs. (+1 extra)
Head Cap Bolt
4 pcs. (+1 extra)
D.
Leg
Floor Leveler
4 pcs. (+1 extra)
Advertisement
Table of Contents
Related Manuals for Home Styles 5168-30
Summary of Contents for Home Styles 5168-30
- Page 1 16 pcs. (+ 1 extra) 1 pc. Spring Small Washer Head Cap Bolt Floor Leveler 16 pcs. (+1 extra) Hex Wrench Hex Wrench 4 pcs. (+1 extra) 4 pcs. (+1 extra) 1 pc. 1 pc. Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319 servicedesk@homestyles-furniture.com...
- Page 2 Assembly Instructions IMPORTANT * Do not tighten up all the screws until each part is properly assembled. * You should keep Hex Wrench and Key Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future. STEP 1 Attach Connect Panel (B) to Post (C), using Flat Washers,...
