IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
A.
Top
1 pc.
E.
Front Stretcher
1 pc.
F.
Back Panel
2 pcs.
G.
Shelf
4 pcs.
Hardware List
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
Tool(s) required for assembly: Phillips screwdriver, Level
Home Styles Customer Service: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com,
88 5134 64
Buffet
M6x35
M8x38
Head Cap Bolt (short)
Wood Screw (long)
6 pcs. (+1 extra)
1 pc. (+1 extra)
M4x19
M6x40
Wood Screw (short)
Head Cap Bolt (long)
12 pcs. (+1 extra)
8 pcs. (+1 extra)
B.
C.
Side Panel
Side Panel
1 pc.
1 pc.
I.
Door
1 pc.
Magnet
2 pcs.
M3x15
Wood Screw
for Magnet
4 pcs. (+1 extra)
888-680-7460, 877-831-0319
D.
Middle Panel
1 pc.
H.
Base
1 pc.
J.
Door
1 pc.
Adjustable Pin
16 pcs. (+1 extra)
Pull Handle
2 pcs.
M8x32
Wood Screw
for Pull Handle
2 pcs. (+1 extra)
