PARTS & DESCRIPTIONS*
5
9
11
1
10
7
6
2
3
4
8
NO IR IR
Lens
1
Power Input Conne ctor
2
12VDC/24VAC Dual Voltage
UTP
3
RS 485
4
Primary Video BNC Output Connector
5
Dome Cover
6
Upper Case
7
Control Board
8
Secondary Video BNC
9
Output Connector
Mounting Screws
10
Joystick
11
5
