Max CN238 Operating And Maintenance Manual

Pneumatic coil nailer
Hide thumbs

Advertisement

Quick Links

Download this manual
CN238
PNEUMATIC COIL NAILER
DRUCKLUFT-COIL-NAGLER
CLOUEUSES PNEUMATIQUES
A BOBINES
SPARACHIODI AD ARIA COMPRESSA
CON CARICAMENTO A ROTOLO
CLAVADORAS NEUMATICAS PARA
ROLLOS DE CLAVOS
MANUALE DI FUNZIONAMENTO E MANUTENZIONE
MANUAL DE OPERACIONES Y MANTENIMIENTO
WARNING:
ACHTUNG!
AVERTISSEMENT:
ATTENZIONE:
ATENCI :
OPERATING and MAINTENANCE MANUAL
BETRIEBSANLEITUNG
MANUEL D UTILISATION et D ENTRETIEN
BEFORE USING THIS TOOL, STUDY THIS MANUAL TO ENSURE SAFET Y WARNING AND
INSTRUCTIONS.
KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE.
LESEN SIE VOR INBETRIEBNAHME DES GER\TES DIE GEBRAUCHS- UND SICHERHEITS-HINWEISE.
BITTE BEWAHREN SIE DIE GEBRAUCHS- UND SICHERHEITSHINWEISE AUF, DAMIT SIE AUCH SP\TER
EINGESEHEN WERDEN K NEN.
AVANT D UTILISER CET OUTIL, LIRE CE MANUEL ET LES CONSIGNES DE SECURITE AFIN DE
GARANTIR UN FONCTIONNEMENT SUR.
CONSERVER CE MANUEL EN LIEU SUR AVEC L OUTIL AFIN DE POUVOIR LE CONSULTER
ULTERIEUREMENT.
PRIMA DI USARE QUESTA MACCHINA, STUDIARE IL MANUALE PER PRENDERE ATTO DEGLI
AVVERTIMENTI E DELLE ISTRUZIONIPER LA SICUREZZA.
TENERE QUESTE ISTRUZIONI INSIEME ALLO STRUMENTO PER CONSULTAZIONI FUTURE
PARA EVITAR GRAVES DAОS PERSONALES O EN LA PROPIEDAD.
ANTES DE EMPLEAR LA HERRAMIENTA, LEER CON ATENCI Y COMPRENDER LOS SIGUIENTES
INSTRUCCIONES DE SEGURIDAD.

Advertisement

loading

Related Manuals for Max CN238

Summary of Contents for Max CN238

  • Page 1 CN238 PNEUMATIC COIL NAILER DRUCKLUFT-COIL-NAGLER CLOUEUSES PNEUMATIQUES A BOBINES SPARACHIODI AD ARIA COMPRESSA CON CARICAMENTO A ROTOLO CLAVADORAS NEUMATICAS PARA ROLLOS DE CLAVOS OPERATING and MAINTENANCE MANUAL BETRIEBSANLEITUNG MANUEL D UTILISATION et D ENTRETIEN MANUALE DI FUNZIONAMENTO E MANUTENZIONE MANUAL DE OPERACIONES Y MANTENIMIENTO...
  • Page 2 ENGLISH Page 3 to 13 Page DEUTSCH Page 15 to 25 Page FRAN IS Page 27 to 37 Page ITALIANO Page 39 to 49 Page ESPAОL Page 51 to 61 Page DEFINITIONS OF SIGNAL WORDS WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

  • Page 3: Table Of Contents

    ENGLISH CN238 PNEUMATIC COIL NAILER INDEX 1. SAFETY INSTRUCTIONS ……………… 4 2. SPECIFICATIONS & TECHNICAL DATA ……………………… 7 3. AIR SUPPLY AND CONNECTIONS ……… 8 4. INSTRUCTIONS FOR OPERATION ……… 9 5. MAINTAIN FOR PERFORMANCE ……… 13 6. STORING …………………………… 13 7.

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS WARNING: TO AVOID SEVERE PERSONAL INJURY OR PROPERTY DAMAGE BEFORE USING THE TOOL, READ CAREFULLY AND UNDERSTAND THE FOLLOWING SAFET Y INSTRUCTIONS . FAILURE TO FOLLOW WARNINGS COULD RESULT IN DEATH OR SERIOUS INJURY. PRECAUTIONS ON USING THE TOOL WEAR SAFETY GLASSES OR GOGGLES Danger to the eyes always exists due to the possibility of dust being blown up by the exhausted air or of a fastener flying up due to the improper handling of the tool.
  • Page 5 INSPECT SCREW TIGHTNESS Loose or improperly installed screws or bolts cause accidents and tool damage when the tool is put into operation. Inspect to confirm that all screws and bolts are tight and properly installed prior to operating the tool. DO NOT TOUCH THE TRIGGER UNLESS YOU INTEND TO DRIVE A FASTENER Whenever the air supply is connected to the tool, never touch the trigger unless you intend to drive a fastener into the work.
  • Page 6 Keep the tool in a dry place out of reach of children when not in use. Do not use the tool without Safety Warning label. Do not modify the tool from original design or function without approval by MAX CO., LTD.

  • Page 7: Specifications

    2. SPECIFICATIONS AND TECHNICAL DATA q Frame w Cylinder Cap e Contact Arm r Nose t Magazine y Trigger u Grip i Exhaust o Trigger Lock Dial 2. TOOL SPECIFICATIONS 3. FASTENER SPECIFICATIONS PLASTIC SHEET COLLATED HEIGHT 249 mm (9-7/8©) NAIL LENGTH 17 to 38 mm (11/16©...

  • Page 8: Air Supply And Connections

    Regulator Air compressor Air filter Oiler HOSES: Hose has a min. ID of 6 mm (1/4©) and max. length of no more than 5 Air hose meters (17©). The supply hose should contain a fitting that will provide quick disconnecting from the male plug on the tool.

  • Page 9: Instructions For Operation

    4. INSTRUCTIONS FOR OPERATION Read section titled SAFETY INSTRUCTIONS . BEFORE OPERATION q Wear Safety Glasses or Goggles. w Do not connect the air supply. e Inspect screw tightness. r Check operation of the contact arm & trigger if moving smoothly. t Connect the air supply.
  • Page 10 e Nail loading: Nail Place a coil of nails over the post in the magazine. Uncoil enough nails to reach the feed pawl, and place the second nail between the teeth on the feed pawl. The nail heads fit in slot on nose. Feed pawl r Swing cover closed.
  • Page 11 SEQUENTIAL TRIP The Sequential Trip requires the operator to hold the tool against the work before pulling the trigger. This makes accurate fastener placement easier, for instance on framing, toe nailing and crating applications. The Sequential Trip allows exact fastener location without the possibility of driving a second fastener on recoil, as described under Contact Trip .
  • Page 12 As nails are driven the plastic sheet will feed out of the tool. When sufficient strip has been fed out it can be torn away by pulling against the tear edge in the nose. ADDITIONAL INSTRUCTIONS FOR CN238 COIL NAILER METAL CONTACT TIP FOR FLOORING APPLICATION CONTACT TIP REPLACEMENT ALWAYS disconnect air supply before attaching / detaching the contact tip.

  • Page 13: Maintain For Performance

    All quality tools will eventually require servicing or replacement of parts because of wear from the normal use. 7. TROUBLE SHOOTING/REPAIRS The troubleshooting and/or repairs shall be carried out only by the MAX CO., LTD. authorised distributors or by other specialists.
  • Page 14 I contenuti di questo manuale possono essere cambiati senza preavviso per motivi 6-6 NIHONBASHI-HAKOZAKI-CHO, CHUO-KU, TOKYO, JAPAN Tel: (03) 3669-8131 Telefax: (03) 3669-7104 http://www.maxusacorp.com (USA Site) http://www.max-ltd.co.jp/int/ (GLOBAL Site) PRINTED IN JAPAN GEDRUCKT IN JAPAN IMPRIM AU JAPON STAMPATO IN GIAPPONE IMPRESO EN JAP...
