  • Page 1 CN565S CN565D PNEUMATIC COIL NAILER DRUCKLUFT-COIL-NAGLER CLOUEUSES PNEUMATIQUES A BOBINES SPARACHIODI AD ARIA COMPRESSA CON CARICAMENTO A ROTOLO CLAVADORAS NEUMATICAS PARA ROLLOS DE CLAVOS OPERATING and MAINTENANCE MANUAL BETRIEBSANLEITUNG MANUEL D’UTILISATION et D’ENTRETIEN MANUALE DI FUNZIONAMENTO E MANUTENZIONE MANUAL DE OPERACIONES Y MANTENIMIENTO...
  • Page 2 INDEX INHALTSVERZEICHNIS INDEX INDICE INDICE ENGLISH Page 3 to 14 Page DEUTSCH Page 15 to 26 Page FRANÇAIS Page 27 to 38 Page ITALIANO Page 39 to 50 Page ESPAÑOL Page 51 to 62 Page DEFINITIONS OF SIGNAL WORDS WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
  • Page 3: Table Of Contents

    ENGLISH CN565S /CN565D PNEUMATIC COIL NAILER INDEX 1. SAFETY INSTRUCTIONS ……………4 2. SPECIFICATIONS & TECHNICAL DATA……………………7 3. AIR SUPPLY AND CONNECTIONS …9 4. INSTRUCTIONS FOR OPERATION …10 5. MAINTAIN FOR PERFORMANCE …14 6. STORING ……………………………14 7. TROUBLESHOOTING/REPAIRS……14 OPERATING and MAINTENANCE MANUAL...
  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS WARNING: TO AVOID SEVERE PERSONAL INJURY OR PROPERTY DAMAGE BEFORE USING THE TOOL, READ CAREFULLY AND UNDERSTAND THE FOLLOWING “SAFETY INSTRUCTIONS”. FAILURE TO FOLLOW WARNINGS COULD RESULT IN DEATH OR SERIOUS INJURY. PRECAUTIONS ON USING THE TOOL WEAR SAFETY GLASSES OR GOGGLES Danger to the eyes always exists due to the possibility of dust being blown up by the exhausted air or of a fastener flying up due to the improper handling of the tool.
  • Page 5 INSPECT SCREW TIGHTNESS Loose or improperly installed screws or bolts cause accidents and tool damage when the tool is put into operation. Inspect to confirm that all screws and bolts are tight and properly installed prior to operating the tool. DO NOT TOUCH THE TRIGGER UNLESS YOU INTEND TO DRIVE A FASTENER Whenever the air supply is connected to the tool, never touch the trigger unless you intend to drive a fastener into the work.
  • Page 6 • Keep the tool in a dry place out of reach of children when not in use. • Do not use the tool without Safety Warning label. • Do not modify the tool from original design or function without approval by MAX CO., LTD.
  • Page 7: Specifications & Technical Data

    Contact Arm r Nose t Magazine y Trigger u Grip i Exhaust Cover o Trigger Lock Dial 2. TOOL SPECIFICATIONS PRODUCT NO. CN565S CN565D HEIGHT 12-9/16˝ (320 mm) 12-9/16˝ (320 mm) WIDTH 5-1/8˝ (130 mm) 5-1/8˝ (130 mm) LENGTH 10-3/4˝...
  • Page 8 4. TECHNICAL DATA q NOISE A-weighted single-event ------ LWA, 1s, d 95.7 dB sound power level A-weighted single-event ------ L p A , 1s, d 87.7 dB emission sound pressure level at work station These values are determined and documented in accordance to EN12549 : 1999. w VIBRATION Vibration characteristic value =...
  • Page 9: Air Supply And Connections

    Air compressor Air filter Oiler HOSES: Hose has a min. ID of 1/4˝ (6 mm) and max. length of no more than 17˝ (5 Air hose meters). The supply hose should contain a fitting that will provide “quick disconnecting” from the male plug on the tool.
  • Page 10: Instructions For Operation

    4. INSTRUCTIONS FOR OPERATION Read section titled “SAFETY INSTRUCTIONS”. BEFORE OPERATION q Wear Safety Glasses or Goggles. w Do not connect the air supply. e Inspect screw tightness. r Check operation of the contact arm & trigger if moving smoothly. t Connect the air supply.
  • Page 11 DRIVING FASTENERS CONTACT TRIP MODEL w/ANTI-DOUBLE FIRE MECHANISM (CN565S) The anti-double fire mechanism (US patent 5597106, UK patent 2286790) is installed on this tool. The common operating procedure on “Contact Trip” tools is for the operator to contact the work to actuate the trip mechanism while keeping the trigger pulled, thus driving a fastener each time the work is contacted.
  • Page 12 (finger still holding trigger pulled) an unwanted second fastener will be driven. CONTACT TRIP (CN565D) Identified by BLACK TRIGGER. CONTACT TRIP WITH ANTI-DOUBLE FIRE MECHANISM (CN565S) (US patent 5597106, UK patent 2286790) Identified by RED TRIGGER. SEQUENTIAL TRIP The Sequential Trip requires the operator to hold the tool against the work before pulling the trigger.
  • Page 13 DRIVING DEPTH ADJUSTMENT DIAL WARNING: ALWAYS disconnect air supply before adjustment dial. q With air pressure set, drive nails into a representative material sample to determine Adjustment dial if adjustment is necessary. Deeper w If adjustment is required, disconnect air supply. Shallow e Refer to the mark on the contact arm for direction to turn the adjustment dial.
  • Page 14: Maintain For Performance

    All quality tools will eventually require servicing or replacement of parts because of wear from the normal use. 7. TROUBLE SHOOTING/REPAIRS The troubleshooting and/or repairs shall be carried out only by the MAX CO., LTD. authorised distributors or by other specialists. Supplement to the operating instruction According to the European Norm EN 792-13 the regulation is valid from 01.01.2001 that all fastener...
  • Page 15 • El contenido de este manual puede ser cambiado sin noticia previa para mejoramiento. 〔 〕 6-6 NIHONBASHI-HAKOZAKI-CHO, CHUO-KU, TOKYO, JAPAN Tel: (03) 3669-8131 Telefax: (03) 3669-7104 www.maxusacorp.com (USA Site) www.max-ltd.co.jp/int/ (GLOBAL Site) 060823-01/01 PRINTED IN JAPAN GEDRUCKT IN JAPAN IMPRIMÉ AU JAPON STAMPATO IN GIAPPONE...
