Pipishell PISL2 Installation Instructions Manual page 6

4A-1
4A-2
4A-3
4A-4
A1
Use a stud finder(not
included)to locate wood
studs. Mark the edge and
center locations.
Position the wall plate at
your desired height and
line up the holes with your
stud center line. Level the
wall plate and mark the
holes.
Drill 4 pilot holes using a 4
mm diameter drill bit. Make
sure the depth is not less
than 50mm.
Install the wall plate [01] using lag
bolts [A1] . Tighten the lag bolts
[A1] only until they are pulled
firmly against the wall plate.
5
50mm
ø4mm
Socket Wrench
