QorIQ LS1043A Reference Design
Board Quick Start
1 Introduction
This document describes the LS1043A reference design board
(LS1043ARDB) and hardware kit containing the board. It also
explains the basic board operations in a step-by-step manner.
This document describes the settings required to connect
switches, connectors, jumpers, push buttons, and LEDs to the
peripheral devices.
The LS1043ARDB functions with an integrated development
environment (IDE), such as Freescale CodeWarrior. The
instructions for working with the IDE are beyond the scope of
this document.
The list of items included in the LS1043ARDB hardware kit is
provided with the LS1043ARDB board support package
(BSP). Optional hardware components that are not included in
the LS1043ARDB hardware kit are:
• TDM modules
• PCIe/mini-PCIe cards
• CodeWarrior TAP (CWTAP)
2 Related documentation
The table below lists and explains the additional documents
that you can refer to, for more information about
LS1043ARDB.
© 2015 Freescale Semiconductor, Inc.
Document Number: LS1043ARDBQS
Contents
1
Introduction.............................. .............................. 1
2
Related documentation..................... .......................1
3
LS1043ARDB system board interface ....................2
4
Getting started with LS1043ARDB.... ....................3
5
Switch configurations................... ..........................4
6
Jumper settings......................... .............................. 8
7
Interfaces.................................................................9
8
Connectors.............................................................16
9
Push and slide buttons........................................... 18
10
LED indicators........................... ...........................19
11
Setting up CodeWarrior TAP............. .................. 21
12
configurations................................... .................... 22
13
NOR flash memory map........................................24
14
Revision history.................................................... 24
Rev. 1, 11/2015
Advertisement
Table of Contents
Related Manuals for Freescale Semiconductor LS1043ARDB
Summary of Contents for Freescale Semiconductor LS1043ARDB
-
Page 1: Table Of Contents
IDE are beyond the scope of this document. Push and slide buttons........... 18 The list of items included in the LS1043ARDB hardware kit is LED indicators............19 provided with the LS1043ARDB board support package Setting up CodeWarrior TAP....... 21 (BSP). -
Page 2: Ls1043Ardb System Board Interface
Contains information on LS1043A pin assignments, electrical characteristics, hardware design considerations, package information, and ordering information 3 LS1043ARDB system board interface The figure below shows the front view of the LS1043ARDB. Figure 1. LS1043ARDB front view The figure below shows the rear view of the LS1043ARDB. -
Page 3: Getting Started With Ls1043Ardb
4.1 Prepare board To ensure correct board setup, prepare the board using the steps below: 1. Verify that the LS1043ARDB hardware kit contains all items mentioned in the kit contents list provided with the LS1043ARDB packing list. 2. Verify the LS1043ARDB dual inline package (DIP) switch settings. See Switch configurations for details. -
Page 4: Switch Configurations
To restart or reset the system, use the reset button next to the UART port (RJ45 without LED). 5 Switch configurations In the LS1043ARDB, the configuration switches are arranged along the edge of the board. Use the following figure as a reference. - Page 5 Switch configurations 5.1 SW3 configuration The figure below shows the SW3 switch on the LS1043ARDB. ON '1' CLKGEN_FS0 CLKGEN_FS1 UART_SEL SD1REFCLK_SEL EVDD_SEL OPENSDA_EN TDMCLK_SD/USB SDHC_SPICS_SEL Figure 4. SW3 switch The table below describes the SW3 configuration. Table 2. SW3 configuration...
- Page 6 • 1: SDHC/USB (default value) SW3[8] SDHC_SPICS SDHC_DAT[4:7] or SPI_CS select • 0: SDHC • 1: SPI_CS (default value) 5.2 SW4 configuration The figure below shows the SW4 switch on the LS1043ARDB. ON '1' RCW_SRC0 RCW_SRC1 RCW_SRC2 RCW_SRC3 RCW_SRC4 RCW_SRC5...
- Page 7 NOTE: The RCW_SRC field (9 bits) is spread SW4[7] RCW_SRC6 over SW4 and SW5. SW4[8] RCW_SRC7 SW5[1] RCW_SRC8 5.3 SW5 configuration The figure below shows the SW5 switch on the LS1043ARDB. RCW_SRC8 SYSCLK_SEL CFG_TEST_SEL_B BANK_SEL0 BANK_SEL1 BANK_SEL2 SW_SVR1 SW_SVR0 ON '1' Figure 6.
-
Page 8: Jumper Settings
SW5[7] SW_SVR1 SVR[1:0] • 00: Reserved (default value for SW5[8] SW_SVR0 LS1043A) 6 Jumper settings The table below lists the factory default jumper settings for the LS1043ARDB. Table 5. LS1043ARDB jumper settings Jumper Size Name/function Description 1x2 pin Remote reset •... -
Page 9: Interfaces
This section describes the interfaces for the LS1043ARDB. 7.1 UART interfaces The LS1043ARDB supports two UART interfaces, UART1 and UART2. You can use UART1 as a console port. On the LS1043ARDB, you can use UART1 in two ways: QorIQ LS1043A Reference Design Board Quick Start, Rev. 1, 11/2015... - Page 10 SW3[3] is used to select UART1. The figure below shows UART1 connection using the RJ45 connector when SW3[3] is OFF. UART1 port Figure 8. UART1 connection using RJ45 connector The figure below shows UART1 connection using mini-USB when SW3[3] is ON. QorIQ LS1043A Reference Design Board Quick Start, Rev. 1, 11/2015 Freescale Semiconductor, Inc.
- Page 11 7.2 Ethernet interfaces The LS1043ARDB has six 100M/1G Ethernet ports (four QSGMII ports and two RGMII ports) and one 10G Ethernet port. Connection is made directly using an RJ45 connector. Connect an appropriate cable (CAT 5E or better) between the RJ45 and target system.
- Page 12 7.3 PCI express cards The LS1043ARDB supports one peripheral component interconnect (PCI) express slot and one mini-PCI express slot. Install the desired device in the appropriate slot. NOTE The PCI express card images shown in this section are only for demonstration purposes.
- Page 13 To install a mini-PCI express card on the LS1043ARDB, perform these steps: 1. Add the soft thermal pad, available in the LS1043ARDB hardware kit, on the LS1043ARDB, before you install a Wi- Fi card on the board (see figure below).
- Page 14 Interfaces Figure 12. Soft thermal pad installation 2. Attach the mini-PCI express card to the LS1043ARDB, as shown in the figure below. QorIQ LS1043A Reference Design Board Quick Start, Rev. 1, 11/2015 Freescale Semiconductor, Inc.
- Page 15 7.4 TDM riser card The LS1043ARDB supports the Freescale time-division multiplexing (TDM) riser card (part number: TDM-DS26522). You need to use an adapter board (part number: X-TDM-ADP) to install the TDM riser card on the LS1043ARDB. NOTE The TDM riser card and adapter board are not provided with the LS1043ARDB hardware kit.
-
Page 16: Connectors
Connectors TDM riser card Adapter board Figure 14. TDM card installation 8 Connectors The table below lists the connectors available on the LS1043ARDB. Table 7. LS1043ARDB connectors Connector Description Connector type Typical connection DC power switch 3-pin ON/OFF switch Turns power ON/OFF... - Page 17 • USB1: Top • USB2: Bottom RTC battery 3-pin battery holder Connects to 3 V coin battery The figure below shows the connector locations on the LS1043ARDB. QorIQ LS1043A Reference Design Board Quick Start, Rev. 1, 11/2015 Freescale Semiconductor, Inc.
-
Page 18: Push And Slide Buttons
Mini-USB to UART1 Figure 15. Connector locations on LS1043ARDB 9 Push and slide buttons The table below describes the functions of the LS1043ARDB push button and slide switch. QorIQ LS1043A Reference Design Board Quick Start, Rev. 1, 11/2015 Freescale Semiconductor, Inc. -
Page 19: Led Indicators
The figure below shows the push/slide button locations. Power Reset switch switch Figure 16. LS1043ARDB buttons 10 LED indicators The table below explains the light emitting diodes (LEDs) on the LS1043ARDB. Table 9. LS1043ARDB LEDs Color Positioned on Name Description Green Power LED (3.3 V) - Page 20 Power LED (3.3 V) • OFF: 3.3 V power is OFF • ON: 3.3 V power is supplied The figure below shows the LED locations on the LS1043ARDB. QorIQ LS1043A Reference Design Board Quick Start, Rev. 1, 11/2015 Freescale Semiconductor, Inc.
-
Page 21: Setting Up Codewarrior Tap
"TX ACT" Figure 17. LS1043ARDB LED locations 11 Setting up CodeWarrior TAP The CodeWarrior TAP allows you to debug and control of the LS1043ARDB system using the CodeWarrior IDE. NOTE No CodeWarrior TAP is included in the LS1043ARDB hardware kit. -
Page 22: Ls1043Ardb Operating Configurations
JTAG header 10-pin adapter Figure 18. CodeWarrior installation 3. Install the free end of the cable to J16 on the LS1043ARDB. NOTE The connector is keyed to prevent reversal. When properly aligned, the red stripe will be nearest to the board edge. - Page 23 VREF (DDR VREF voltage) DDR VREF voltage power supply 0.6 V VTT1 (DDR3_VTT voltage) DDR3 termination voltage power supply 0.6 V The table below shows the default LS1043ARDB clock rates. Table 11. LS1043ARDB clock rates Clock Description Frequency Core clock...
-
Page 24: Nor Flash Memory Map
Change description Rev. 1 11/2015 Power up and use board Updated console output TDM riser card Added as a new section Table continues on the next page... QorIQ LS1043A Reference Design Board Quick Start, Rev. 1, 11/2015 Freescale Semiconductor, Inc. - Page 25 Revision history Table 13. Revision history (continued) Revision Date Topic cross-reference Change description LS1043ARDB operating Changed core clock frequency from 1500 MHz configurations to 1600 MHz in Table 11 Rev. 0 08/2015 Initial public release QorIQ LS1043A Reference Design Board Quick Start, Rev. 1, 11/2015...
- Page 26 Freescale, the Freescale logo, and QorIQ are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. Layerscape and QUICC Engine are trademarks of Freescale Semiconductor, Inc. All other product or service names are the property of their respective owners.
