M52259DEMOKIT—Quick Start Guide
ColdFire
Embedded Controllers
®
M52259DEMOKIT
One-stop-shop connectivity MCU with
USB, Ethernet and CAN, featuring
Freescale MQX software solutions
• Quick Start Guide
• Lab Tutorials
• CodeWarrior
™
• Getting Started DVD
Manual
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Freescale Semiconductor M52259DEMOKIT
Summary of Contents for Freescale Semiconductor M52259DEMOKIT
- Page 1 M52259DEMOKIT—Quick Start Guide ColdFire Embedded Controllers ® M52259DEMOKIT One-stop-shop connectivity MCU with USB, Ethernet and CAN, featuring Freescale MQX software solutions • Quick Start Guide • Lab Tutorials • CodeWarrior Manual ™ • Getting Started DVD...
- Page 2 Get to Know the M52259DEMOKIT Board USB connector for debugger (OSBDM) RS232 Ethernet Figure 1. M52259DEMOKIT...
- Page 3 M52259DEMOKIT—Quick Start Guide Step-by-Step Installation Instructions STEP In this Quick Start Guide, you will learn how to set up the board and run the default web server demo. Connect the USB cable Additional labs are available on the between the PC and the...
- Page 4 STEP STEP Connect the RS232 Open Configure Hyper-Terminal cable between the PC for 115200, 8 bits, no flow and the board control, 1 stop bit STEP Open Hyper-Terminal on the PC STEP Connect an Ethernet crossover cable between the PC and the board Reset the board by pressing the reset button.
- Page 5 M52259DEMOKIT—Quick Start Guide STEP no setup. Note: The PC may take a few minutes to default to the auto IP address and make the connection. If necessary, manually set up However, if you have trouble connecting, TCP/IP on the PC...
- Page 6 STEP STEP continued… See image below. Additional Labs Available Choose an appropriate lab document to continue with more instructions: MCF5225x ColdFire TCP/IP Lite Stack • by InterNIche Lab MCF5225x ColdFire USB Lite Stack • by CMX Lab STEP MCF5225x USB Bootloader Lab •...
- Page 7 Freescale products, please visit www.freescale.com/coldfire. Freescale and the Freescale logo are trademarks or registered trademarks of Freescale Semiconductor, Inc. in the U.S. and other countries. All other product or service names are the property of their respective owners. © Freescale Semiconductor, Inc. 2008.
