User's Guide
MPC5777C EVB User Guide
Prototype Board
by: Kumar Sendhil
Automotive Micro-Controller Group
Austin, Texas USA
1.
Introduction
This user guide details the setup and configuration
of the Freescale MPC5777C Evaluation Board
(hereafter referred to as the EVB). The EVB is
intended to provide a mechanism for easy
customer evaluation of the MPC57xx family of
microprocessors, and to facilitate hardware and
software development.
At the time of writing this document, the
MPC57xx
family
powertrain and safety devices. For the latest
product information, please speak to your
Freescale representative or consult the MPC57xx
website at www.freescale.com.
The EVB is intended for bench or laboratory use
and has been designed using normal temperature
specified components (+70°C).
© Freescale, Inc., 2015. All rights reserved.
consists
of
the
55nm
Contents
1.
Introduction ..................................................................... 1
2.
EVB Features ................................................................. 3
Configuration - Motherboard ........................................ 4
3.
4.
5.
6.
Board Interface Connector ........................................... 37
7.
Default Jumper Summary Table ................................... 50
8.
List of Acronyms ........................................................... 53
Document Number:
MPC5777CEVBUG
Rev. 0, 08/2015
