- Page 1 Freescale Semiconductor CSM-56F801 Development Module for Freescale DSP56F801 © Freescale Semiconductor, Inc., 2004. All rights reserved.
-
Page 2: Table Of Contents
2 0 0 5 CONTENTS CAUTIONARY NOTES ......................3 TERMINOLOGY.........................3 CSM-56F801 ..........................4 GETTING STARTED........................5 REFERENCE DOCUMENTATION.....................5 CSM-56F801 OPERATION ......................6 MEMORY MAP........................6 POWER SUPPLY ........................7 PWR ..........................7 CONNECTOR J1....................... 7 PWR_SEL ......................... 8 RESET SWITCH ........................8 LOW-VOLTAGE DETECT ..................... 8 TIMING .......................... -
Page 3: Cautionary Notes
3) EMC Information on the CSM-56F801 module: a) This product as shipped from the factory with associated power supplies and cables, has been verified to meet with requirements of CE and the FCC as a CLASS B product. -
Page 4: Csm-56F801
2 0 0 5 CSM-56F801 The CSM-56F801 is an evaluation or demonstration board for the DSP56F801 digital signal processor. The included wall plug, DB9 serial cable, sample software tools, examples, and debug monitor make application development quick and easy. A JTAG port is provided for development tool application and is compatible with JTAG interface cables and software. -
Page 5: Getting Started
Use of the CSM-56F801 module requires Metrowerks CodeWarrior for Freescale DSP and an Axiom Manufacturing JTAG cable. Both items are available in the CSM-56F801KIT. The JTAG cable supports communications between the CSM-56F801 module and a standard PC. -
Page 6: Csm-56F801 Operation
2 0 0 5 CSM-56F801 OPERATION The CSM-56F801 module provides input and output features to assist embedded application development. Access to MPU port signals is available through connector J1. This connector may also be used to input power to the module or to output power to attached modules. RS- 232 communications signals may also be input through connector J1. -
Page 7: Power Supply
Care should be exercised not to over-drive this input. This connection may also be used to power external modules attached to connector J1. The PWR_SEL option header determines how power is routed to the module. Freescale Semiconductor, Inc. -
Page 8: Pwr_Sel
(LVI) circuit. The POR circuit holds the MPU in reset until voltage reaches an acceptable level. The LVI provides an interrupt out when voltage falls below the trip level. Refer to the MPU User Guide for further details. Freescale Semiconductor, Inc. -
Page 9: Timing
Communications The CSM-56F801 module provides a single RS-232 communications port. An RS-232 transceiver (U2) provides RS-232 signal level to TTL/CMOS logic level translation on the first RS-232 channel. RS232 signals TXD0 and RXD0 are routed between the transceiver and the MCU. -
Page 10: User Options
JTAG / OnCE The JTAG/OnCE 14 pin connector is compatible with the Freescale On Chip Emulation (OnCE) development port. This connector allows the connection of a OnCE style background debug cable for software development, programming and debugging in real-time. Freescale Semiconductor, Inc. -
Page 11: J1 Connector
11 12 /TRST 13 14 J1 Connector Connector J1 provides access to CSM-56F801 I/O port signals. This connector may also be used to power the module or to power off-module circuitry. Figure 4: MCU I/O Connector 2 IREQA* Default Signal Assignment... -
Page 12: Mechanical Details
D O C - 0 3 3 4 - 0 1 0 , R E V D E C E M B E R 2 0 0 5 APPENDIX A Mechanical Details Freescale Semiconductor, Inc. -
Page 13: Bill Of Materials
1 Conn, Dsub, 9P, F, RA, PCB Mount 1 Conn, 2x2 Pin Header, .1" Ctr, Thru PWR_SEL 1 Conn, 2x4 Pin Header, .1" Ctr, Thru USER 1 Conn, 2x7 Pin Header, .1" Ctr, Thru JTAG 1 Conn, 2X20 Pin Header, .1" Ctr, Thru Freescale Semiconductor, Inc. - Page 14 Freescale Semiconductor product could create a situation where personal injury or death may occur. Should Buyer...
