- Page 1 O p e r a t i o n / R e f e r e n c e G u i d e MXA-MP/MPL Modero X Series® Multi Preview and Multi Preview Live U s e r I n t e r f a c e A c c e s s o r i e s...
- Page 2 AMX is not responsible for products returned without a valid RMA number. AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost savings, incidental damages, or consequential damages.
- Page 3 Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
-
Page 5: Table Of Contents
Programming the MXA-MP and MXA-MPL Output ..........14 Resetting the MXA-MP/MPL’s Configuration to Factory Defaults ......14 Resetting the MXA-MP/MPL’s Firmware to Factory Defaults ......... 14 MXA-MPL Latency ....................15 MXA-MP/MPL Best Practices ................17 MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live... - Page 6 Table of Contents MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live...
-
Page 7: Mxa-Mp
® The Modero X Series Multi Preview (FG5968-20) is a touch panel accessory that displays up to 10 preview images on Modero X Series Touch Panels when used in conjunction with an Enova DVX All-In-One Presentation Switcher (FIG. 1). The MXA-MP accepts digital video input signals over HDMI and converts them to JPEG preview images for display on Modero X Series touch panels. -
Page 8: Product Specifications
• Humidity (Storage): 5% to 85% RH • Power (“Heat”) Dissipation: 232 BTU/hr Dimensions: 1 9/16” x 8 1/4” x 7 3/16” (4 cm x 21 cm x 18.2 cm) Weight: 2.80 lbs (1.27 kg) MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live... -
Page 9: Rebooting The Mxa-Mp
Resetting the MXA-MP to Factory Defaults To reset the MXA-MP to its factory defaults, press and hold the Factory Reset button (FIG. 1) on the front of the device for five seconds. MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live... -
Page 10: Mxa-Mpl
MXA-MPL Overview The Modero X Series Multi Preview Live (FG5968-10) is a touch panel accessory that displays a HD digital video stream on Modero X Series Touch Panels when used in conjunction with an Enova DVX All-In-One Presentation Switcher or Enova DGX Digital Media Switcher (FIG. 2). The MXA-MPL accepts digital video inputs over HDMI and converts them to a video stream. -
Page 11: Features
Panel LED: Lights green when device is connected to a panel. Video Output LED: Lights red when sending a video stream to a touch panel. Reset button: Reboots the device when pressed. MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live... -
Page 12: Rebooting The Mxa-Mpl
Resetting the MXA-MPL to Factory Defaults To reset the MXA-MPL to its factory defaults, press and hold the Factory Reset button (FIG. 2) on the front of the device for five seconds. MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live... -
Page 13: Installation
NOTE: For full functionality, the MXA-MP and MXA-MPL should be used with the Enova series media switchers and Modero X Series touch panels. Neither device may be used with previously released AMX touch panels or media switchers. Installing the MXA-MP and MXA-MPL In a network, the MXA-MPL or MXA-MPL must be connected between the Enova DVX or DGX and the Modero X Series touch panel (FIG. -
Page 14: Connecting The Mxa-Mp/Mpl To A Network
In the case of Power Over Ethernet (PoE) Modero X Series touch panels, these panels require the use of an AMX-certified PoE injector. The PoE injector must be connected between the device and the touch panel for proper operation (FIG. 3). -
Page 15: Maximum Power Cable Gauges And Distances
Modero X Series touch panels (MXD/T-2000XL-PAN and MXD/T-1900L-PAN) use external power from an AMX-certified power source. Both the MXA-MP and MXA-MPL may be used as a power source for the panoramic touch panels, but only to certain lengths determined by the cable gauge and the maximum distance between the device and the touch panel. -
Page 16: A Note About Wall And Rack Installation
FIG. 5 shows an AMX device installed in a wall with a filled volume (such as with insulation or concrete), as well as with a closed volume (such as between studs in an otherwise finished wall). The diagram shows how heat generated by the device or other devices may have no way to escape, and may build up to levels that may affect device operation. -
Page 17: Installation Recommendations
Included Accessories: • Installation Screws, #10-32 x .625, Ph. Truss, Black (4) (80-0186) • Washer, #10, Black Nylon (4) (80-0342) • Installation Screws, #4-40 x .187, PFH, Undercut, Black (8) (80-1231-01) MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live... - Page 18 Installing two MXA-MP devices in a Rack Mounting Tray Connect the Rack Mounting Tray to the rack with the provided installation screws. Connect the device to the network and apply power. MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live...
-
Page 19: Configuration
Verify you are using the latest NetLinx Master and Modero firmware, as well as the latest version of NetLinx Studio and TPDesign 4. Configuring the MXA-MP or MXA- MPL in NetLinx Studio requires at least version 3.3, available at www.amx.com. To upload new firmware to the MXA-MP and MXA-MPL: Connect the MXA-MP or MXA-MPL to the intended Modero X Series touch panel and network. -
Page 20: Programming The Mxa-Mp And Mxa-Mpl Output
These Send Commands are accessed by the device through the Modero X Series touch panel. The Send Commands, as well as information on Settings pages, panel configuration, and touch panel programming, may be found in the Modero X Series Programming Guide, available at www.amx.com. Resetting the MXA-MP/MPL’s Configuration to Factory Defaults In certain circumstances, you may need to return the device’s configuration settings to its factory defaults. -
Page 21: Mxa-Mpl Latency
MXA-MPL, may affect this. This may adversely affect touch panel applications that require a shorter period. MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live... - Page 22 Configuration MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live...
-
Page 23: Mxa-Mp/Mpl Best Practices
MXA-MPL or the MXA-MPL and its touch panel, or by the size of the video display on the touch panel. MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live... - Page 24 MXA-MP/MPL Best Practices MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live...
- Page 25 MXA-MP/MPL Best Practices MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live...
- Page 26 - Schedules and registration for any AMX University course - Travel and hotel information - Your individual certification requirements and progress 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...
