    Instruction Manual Tek-DP 1650A Technology Solutions 1 Safety Instructions 1.1 Intended Use Tek-DP 1650A DProbar Multiport Self-Averaging Flow Meter measures the average pressure by taking sample values at different points in the pipe. 1.2 Safety Instructions from the Manufacturer 1.2.1 Disclaimer The manufacturer will not be held accountable for any damage that happens by using its product, including but not limited to direct, indirect, or incidental and consequential damages.
  • Page 5: Packaging, Transportation And Storage

    Instruction Manual Tek-DP 1650A Technology Solutions Warnings and Symbols Used The following safety symbol marks are used in this operation manual and on the instrument. WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or severe injury CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
  • Page 6: Storage

    Instruction Manual Tek-DP 1650A Technology Solutions 1.4.3 Storage If this product is to be stored for a long period of time before installation, take the following precautions: • Store your product in the manufacturer’s original packing used for shipping. • Storage location should conform to the following requirements: 1.
  • Page 7: Dimensional Drawings

    Instruction Manual Tek-DP 1650A Technology Solutions pressure of the liquid. The impact pressure is directly proportional to the flow rate of the liquid. As the liquid flows around the Tek-DP 1650A DProbar, the static pressure ports measure the decrease in pressure downstream of the flow. These pressure differentials are then averaged to determine the flow rate of the liquid using the following formulas: To calculate the volumetric flow rate: = N * K * D...
  • Page 8: Specifications

    Instruction Manual Tek-DP 1650A Technology Solutions 2.4 Specifications Accuracy ± 1 % with 95 % confidence Process Media Liquid, Gas, and Steam Line Sizes 2” to 72” Sizes 3/25/60 mm Operating Temperature Standard at -20°F to 100°F, optional -40°F to 1200°F Material 316L SS 304L SS...
  • Page 9 Instruction Manual Tek-DP 1650A Technology Solutions 18” 20” 24” 30” Meter Body 316 SS STD (Standard Pipe SCH) Pipe Schedule Special Transmitter Remote mount; NPT connection Connection Threaded Connection (300psi) Pressure Rating 150# RF ANSI Special Pipe Fitting 316SS Material (Weld Special and Thread) 1-½”...
  • Page 10: Installation

    Instruction Manual Tek-DP 1650A Technology Solutions Custom Product Code 3 Installation This section covers instructions on installation and commissioning. Installation of the device must be carried out by trained; qualified specialists authorized to perform such works. • Recommended upstream and downstream distances 7D (in plane) 9D (out of plane) 9D (in plane)
  • Page 11: Selection Of Installation Of Locations

    Instruction Manual Tek-DP 1650A Technology Solutions Improper installation has the potential to cause injury and to damage instrument. Periodically inspect the power cables, transducer cables, cable glands and the enclosure for signs of damage. Inspect transducer installation and mounting hardware for loose connections.
  • Page 12: Type Fbr-73 & Fbr-75 Fluid Bar

    Instruction Manual Tek-DP 1650A Technology Solutions 3.1.2 TYPE FBR-73 & FBR-75 FLUID BAR Fig 6: Type FBR-75 Fluid Bar Fig 5: Type FBR-73 Fluid Bar 3.1.3 TYPE FBR-76 FLUID BAR Fig 7: Type FBR-76 Fluid Bar www.tek-trol.com...
  • Page 13: Type Fbf-61 Fluid Bar

    Instruction Manual Tek-DP 1650A Technology Solutions 3.1.4 TYPE FBF-61 FLUID BAR Fig 8: Type FBF-61 Fluid Bar 3.1.5 TYPE FBF-75 & FBF-76 FLUID BAR Fig 10: Type FBF-76 Fluid Bar Fig 9: Type FBF-75 Fluid Bar 3.1.6 TYPE FBF-85 FLUID BAR Fig 11: Type FBF-85 Fluid Bar www.tek-trol.com...
  • Page 14: Type Ftl-73, Ftl-75 & Ftl-76 Fluid Bar

    Instruction Manual Tek-DP 1650A Technology Solutions 3.1.7 TYPE FTL-73, FTL-75 & FTL-76 FLUID BAR Fully inserted Fully retractable Fig 12: Type FTL-73, FTL-75 & FTL-76 Fluid Bar 3.2 Installation Procedure 1. Verify that the line pressure & temperature are within the rated limits for respective models. 2.
  • Page 15: Electrical Connection

    Instruction Manual Tek-DP 1650A Technology Solutions 10. Connect instrument lines to the instrument valves 8 to the appropriate meter, recorder, transmitter w controller. 11. Retract the sensor by rotating the drive nuts counter-clockwise as viewed from the top. The nuts must be turned alternately, about two turns at a time, to prevent binding resulting from unequal loading.
  • Page 16: Grounding Of Measuring Device

    Instruction Manual Tek-DP 1650A Technology Solutions 4.1 Grounding of Measuring Device POWER SUPPLY Fig 13: Grounding of Measuring Device 5 Troubleshooting Fluid Bar operates on natural scientific principles. No moving parts are used in the design, & wear has negligible effect on accuracy. If installed correctly, Fluid Bar will provide a correct flow indication if there is a flow in the pipe.
  • Page 17 Sales: +31 76-2031908 Sales: +971-6526-8344 Support: +1 847-857-6076 Email: tektrol@tek-trol.com www.tek-trol.com Tek-Trol is a fully owned subsidiary of TEKMATION LLC. We o er our customers a comprehensive range of products and solutions for process, power and oil & gas industries. Tek-Trol provides process measurement and control products for Flow, Level, Temperature &...
