Mocka Porto Full Length Hanger Assembly Instructions Manual

Porto Full Length Hanger
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A B
screw 25mm screw 30mm
x4 x2

Hardware Supplied

D E
screw 25mm wall strap
x2
x2
Wall Strap
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
C G
screw 40mm screw 50mm
x2 x23
F
wall plug
x2
WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the
furniture or in the event of an earthquake. Accordingly, we recommend that
H
all furniture is anchored to a wall. We supply a free safety wall anchor with all
furniture sold and we recommend these are used to prevent your product
tipping. The fixing device provided should fit most wall types, but please note
that different wall materials may require different fixing devices from those
supplied.
feet
x4
1
