Porto Three Shelves

Assembly Instructions

Thank you for your purchase.

Please follow the instructions below for correct assembly.

30mm

50mm

screw x12

Hardware Supplied

WARNING:

Any furniture that is not anchored to a wall has the potential to tip over

in certain circumstances, i.e. if a child attempts to climb up on the furniture or in the

event of an earthquake. Accordingly, we recommend that all furniture is anchored

to a wall. We supply a free safety wall anchor with all furniture sold and we

recommend these are used to prevent your product tipping. The fixing device

provided should fit most wall types, but please note that different wall materials

may require different fixing devices from those supplied.

mocka.co.nz | mocka.com.au

safety

wall plug

25mm

strap x2

screw x2

Phillips screwdriver required

Table of Contents

Do you have a question about the Porto and is the answer not in the manual?

Page 1 Porto Three Shelves Assembly Instructions Thank you for your purchase. Please follow the instructions below for correct assembly. 30mm safety 50mm wall plug 25mm screw x12 strap x2 screw x12 screw x2 Hardware Supplied WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain circumstances, i.e.
Page 2 Porto Three Shelves Assembly Instructions Attach panel [2] to the side panels with 4x 30mm screws (A) and 4x Attach panel [1] with 4x 30mm screws (A) and 4x 50mm screws (B) as 50mm screws (B). Tighten with a screwdriver.
Page 3 Porto Three Shelves Assembly Instructions Attach panel [3] and secure with 4x 30mm screws (A). Secure with 4x Move the unit to the desired location against a wall. Attach the other end 50mm screws (B) also, while attaching the 2x safety straps (E) as of the 2x safety straps (E) to the wall using 2x wall plugs (D) and 2x shown.
