Intelligent Weighing Technology IDC Series Setup And Operation page 9

LOCAL SCALE
ID: 654321
0.5512 lb NET
0.11088 lb U.W.
5 PCS
TOTAL
- - - - - - - -
8.2636 lb TW
75 TPC
4 NO
fo an optional line printer for a hardcopy record on "receipt" paper (impact, thermal, thermal
removable roll labels), or to a specific label printer for 2"x2" permanent labels. for configured by for
either a general purpose RS232 line printer, or a specific thermal label printer model OX-2130D
Detail
The scales to printer cable is a DB9
For use with MBS software on a Local Server by COM port, the AJ-MBS scale settings are factory
default, except for output, which is set to continuous. The RS232 settings are all factory default,
except for baud rate, which is set to 9600.
See page 2 for Configuring AJ-MBS scales to MBS software by COM port using:
1) AJ-MBS serial cable with DB9F, 2) Windows computer with DB9M COM or added DB9M by
RS232-to-USB adapter - connected to powered USB, and 3) Compatible MBS COM based
software set to match AJ-MBS scale COM port.
a. Computer administrator rights are required to install VCOM driver (if needed) and optional CTS test
software.
AJ-MBS scales also work with cloud based MBS software using a hardware or software wedge.
See TD104b-Cloud for AJ-MBS scale setup for use with cloud based MBS software.
AJ-MBS Setup Procedure: For locally served MBS using COM ports
1) Step 1 - Setup AJ-MBS scale configuration for COM operation.
a. The parameter menu in the AJ-MBS scale is opened by holding down the
until display changes to "Func", then
Intelligent Weighing Technology, 4040 Adolfo Road, CA, 93012 USA
E-mail: sales@intelligentwt.com
Windows® is registered trademark of the Microsoft Corporation
Page 9 of 15 - TD0116 RevA01 11-30-2016RP
Web Site: www.intelligentwt.com
key is released.
