Intelligent Weighing Technology IDC Series Setup And Operation page 12

1. Setup CTS – for scale to computer COM link testing
a. If RS232-to-USB adapter will be used - install device driver - if not already done.
i. Install driver for RS232-to-USB adapter and VCOM per adapter instructions.
ii. After installation, check COM port assigned in Windows, as found in Control
b. Download and install CTS Test Software from MicroRidge web site.
i. See Appendix C for CTS download instructions
c. Run and Setup CTS RS232 Settings - for scale to computer testing as below.
i. Run CTS software - screen view below (with
ii. Serial ports setup - Press
iii. Click
d. CTS is now ready to test scale to computer link over COM port.
2. CTS Test 1 – scale output validation
Intelligent Weighing Technology, 4040 Adolfo Road, CA, 93012 USA
E-mail: sales@intelligentwt.com
Panel – Device Manger port listing, i.e.
1. Set COM port to scale COM port (select in check box at left).
2. Set RS232 for scale - Baud:9600, Parity:N, Databit: 8, Stopbits:2
to close
Page 12 of 15 - TD0116 RevA01 11-30-2016RP
Web Site: www.intelligentwt.com
button (lower right corner) to open window
setup window.
Phone: +1-805-642-3034 Fax: +1-805-642-4034
©
Intelligent Weighing Technology 2016.
setup window opened)
