Intelligent Weighing Technology LM-300 Operation Manual

Lm series bench/floor scale
Hide thumbs

Advertisement

Table of Contents

LM SERIES
BENCH/FLOOR SCALE
OPERATION MANUAL
PLEASE READ THIS INSTRUCTION MANUAL VERY CAREFULLY BEFORE ATTEMPTING
TO OPERATE THIS SCALE
AUGUST 2003 REV 1
Specifications subject to change without prior notice

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LM-300 and is the answer not in the manual?

Questions and answers

Related Manuals for Intelligent Weighing Technology LM-300

Summary of Contents for Intelligent Weighing Technology LM-300

  • Page 1 LM SERIES BENCH/FLOOR SCALE OPERATION MANUAL PLEASE READ THIS INSTRUCTION MANUAL VERY CAREFULLY BEFORE ATTEMPTING TO OPERATE THIS SCALE AUGUST 2003 REV 1 Specifications subject to change without prior notice...

  • Page 2: Table Of Contents

    CONTENTS INSTALLATION SPECIFICATIONS KEYBOARD LAYOUT AND DESCRIPTION INSTRUCTIONS FOR USE TROUBLE SHOOTING DAILY CARE AND MAINTENANCE INSTALLATION DIAGRAMS...

  • Page 3: Installation

    INSTALLATION CHECK and make sure that the following accessories are included inside the package. This Operation Manual, Indicator x 1, Platform + stainless steel cover x 1, Mains adapter x 1, Pillar x 1 and Screws & tool set x 1. Contact your dealer if any items are miss ing.

  • Page 4: Specifications

    2. SPECIFICATIONS GENERAL SPECIFICATIONS Model No. Capacity Division LM-300 660 lb 0.1 lb LM-600 1320 lb 0.2 lb 19.7 x 23.6” Platform size Power source Built-in rechargeable battery or power adaptor Max. Tare range Up to 100% of rated capacity Max.

  • Page 5: Keyboard Layout And Description

    3. KEYBOARD LAYOUT AND DESCRIPTION ON/OFF KEY Press t his key to turn scale on or off. 2. MODE KEY Press this key to switch between metric and avoirdupois weight units with or without backlight (optional). M+ KEY Press this key to enter present weight value into memory. 4.

  • Page 6: Instructions For Use

    9. TARE INDICATOR An arrow will appear and point at this sign when the tare function is being employed. 10. M+ INDICATOR An arrow will appear and point at this sign when the memory contains data. 11. WEIGHT UNIT INDICATOR "kg"...
  • Page 7 press and hold TARE, then press ON/OFF. Scale displays “F.1” press TARE twice. Scale displays ”F.3 ” press and hold MODE press MODE unit the “ lb” signs appear(or select “kg” to disable the pound unit) press ZERO to confirm and return to normal operation status. (If the pound weight is selected) Press MODE to shift among, lb and lb/oz during operation.

  • Page 8: Trouble Shooting

    4.8.2 Recall Weight Accumulated Press MR, scale displays total number of entries and total accumulated weight of these translations. Scale return to normal operation status 2 seconds after accumulated weight displayed. 4.8.3 Memory Clear Press and hold MR, then press TARE after accumulated weight display. Scale displays “P.0”...
  • Page 9 SYNDROME SCALE TURNED ON BUT ZERO WEIGH T CAN NOT BE ATTAINED CHECK Is anything load applied to platform? ACTION Remove all loads from platform. CHECK Is the scale affect by air flow, vibration or RF? ACTION Place scale away from all disturbances. SYNDROME RATED CAPACITY CANNOT BE ATTAINE D CHECK...

  • Page 10: Daily Care And Maintenance

    6. DAILY CARE AND MAINTENANCE Clean the platform and indicator with a soft and damp cloth, if necessary with a mild detergent. Do not use any harsh, abrasive material, acetone, volatile solvent, thinner or alcohol for cleaning. Verify the accuracy of the scale periodically. Re -calibrate the scale when needed.

This manual is also suitable for:

Lm-600
