affect the display of the channels and do not have any effect on
the channel settings in the ADC register map.
Display Units and Axis Controls(16)
Click Display Units to select whether the data graph displays in
units of voltages or codes. This affects both the Waveform
Graph and the Histogram Graph. The axis controls can be
switched between dynamic and fixed. When "dynamic" is
switched on the axis with automatically adjust to show the
entire range of the ADC results after each batch of sample.
When "fixed" is used the user can program the axis ranges and
they will not adjust after each sample batch.

HISTOGRAM TAB (19)

Histogram Graph and Controls(20 & 21)
The data histogram shows each the number of times each
sample of the ADC output occurs. The control toolbar (21) in
Figure 9. Waveform Tab of the AD7175-2
Rev. Pr.C | Page 10 of 12
EVAL-AD7175-2SDZ User Guide
CRC Error (17)
This LED icon illuminates when a cyclic redundancy check
(CRC) error is detected in the communications between the
software and the AD7175-2. The CRC functionality on the
AD7175-2 is disabled by default and must be enabled for this
indicator to work.
Noise Analysis (18)
This section displays the results of the noise analysis for the
selected analysis channel. This includes both noise and
resolution measurements.
Evaluation Board Software
the graph allows you to zoom in on the data. Change the scales
on the graph by typing values into the x-axis and y-axis.
