EVAL-AD7175-2SDZ User Guide
EVAL-AD7175-2SDZ

RECOMMENDED QUICK START GUIDE

Follow these steps to set up the board:
1. Disconnect the SDP-B board from the USB port of the PC.
Install the EVAL-AD7175-2SDZ
enclosed CD. Restart the PC after installation.
2. Connect the EVAL-SDP-CB1Z
EVAL-AD7175-2SDZ board, as shown in Figure 2.
3. Fasten the two boards with the enclosed plastic
screw washer set.
4. Connect the external 9 V power supply to Connector J5 of
the EVAL-AD7175-2SDZ
LK2 to Position B.
5. Connect the SDP board to the PC via the USB cable. For
Windows® XP, you may need to search for the SDP drivers.
Choose to automatically search for the drivers for the
board if prompted by the operating system.
6. Launch the EVAL-AD7175-2SDZ
Analog Devices subfolder in the Programs menu.
QUICK START GUIDE
software from the
board to the
board as shown in Figure 2. Set
SDP-B
software from the
TBD
Figure 2. Hardware Configuration, Setting Up the

QUICK START NOISE TEST

Use the following procedure to quickly test the noise
performance:
1. Insert Link LK5 to Link LK9 to initiate the noise
performance test mode. In this mode, analog input
channels short to the REFOUT pin.
Click Start Sampling to acquire samples from the ADC
2.
(see Figure 7).
The Samples numeric control in the top right corner of the
main window sets the number of samples collected in each
batch.
EVAL-AD7175-2SDZ
Rev. Pr.C | Page 3 of 12
UG-AD7175-2
